Telwin Parts for Inverter SUPERIOR TIG 322 AC/DC HF/LIFT 400V
TELWIN Authorized Technical Assistance , original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Inverter Welding SUPERIOR TIG 322 AC/DC HF/LIFT 400V - 816016
In the following table, look for the model of the Welding and the respective parts of the code.
| SUPERIOR TIG 322 AC/DC HF/LIFT 400V - 816016 | ||
| # | Part Num. | Description |
| 1 | 113233 | RELAY ' |
| 2 | 113603 | IGBT |
| 3 | 113870 | SENSOR HALL |
| 4 | 116603 | IGBT |
| 5 | 116740 | CAPACITOR |
| 6 | 111249 | DIODE 55A 600V |
| 7 | 116747 | REACTOR |
| 8 | 116759 | RESISTANCE |
| 9 | 116836 | SENSOR HALL |
| 10 | 121029 | SOLENOID |
| 11 | 121481 | THERMOSTAT |
| 12 | 122017 | SWITCH |
| 13 | 122159 | FUSE |
| 14 | 122437 | FUSE |
| 15 | 121325 | THERMOSTAT |
| 16 | 122713 | JACK FOR TORCH |
| 17 | 124321 | WIRING CONTROL |
| 18 | 124324 | WIRING G.R.A. |
| 19 | 132026 | CABLE ALIM. 4G2.5 2 M |
| 20 | 152000 | FAN |
| 21 | 990987 | TRANSFORMER AUXILIARY |
| 22 | 169550 | REACTOR |
| 23 | 169627 | TRANSFORMER |
| 24 | 314357 | FRONT PANEL |
| 25 | 322881 | FRONT |
| 26 | 322882 | RETRO |
| 27 | 322883 | HANDLE |
| 28 | 323001 | FOOT |
| 29 | 323101 | SWITCH KNOB ASSY |
| 30 | 602052 | WATER CONNECTION |
| 31 | 656031 | COAT |
| 32 | 712036 | SOCKET DX 50 |
| 33 | 980548 | CONNECTION KIT INLET GAS |
| 34 | 980772 | BLACK KNOB SET |
| 35 | 980817 | KIT FUND |
| 36 | 981521 | DATA ENTRY FILTER KIT |
| 37 | 981081 | BOARD KIT PRIMARY |
| 38 | 981082 | KIT HF TRANSFORMER |
| 39 | 981083 | KIT POWER TRANSFORMER |
| 40 | 981084 | KIT FORM SECONDARY |
| 41 | 981085 | BOARD KIT INDUCTOR |
| 42 | 981053 | BOARD KIT HF / SURVOLT. |
| 43 | 981075 | KIT PANEL + CARD |
| 44 | 990439 | GLAND KIT |
| 45 | 112828 | CAPACITOR |
| 46 | 112949 | PHASE RECTIFIER |
| 48 | 113747 | DIODE |
| 49 | 111092 | DIODE |
| 50 | 116967 | CAPACITOR |
| 51 | 116325 | DIODE |
| 52 | 116442 | DIODE |
| 53 | 116465 | RESISTANCE |
| 54 | 116644 | IGBT |
| 55 | 116821 | REACTOR |
| 56 | 116937 | TRANSFORMER X booster |
| 57 | 116940 | CAPACITOR |
| 58 | 122571 | THERMOSTAT |
