Telwin Spare Parts for Welding Inverter Tecnica TIG 190 DC-LIFT VRD
€2.92
Tax included
Telwin Spare Parts for Welding Inverter Tecnica TIG 190 DC-LIFT VRD
We are TELWIN authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair problem for Welding Inverter Tig Tecnica TIG 190 DC-LIFT VRD 230V-816219.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Telwin Spare Parts for Welding Inverter Tecnica TIG 190 DC-LIFT VRD
We are TELWIN authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair problem for Welding Inverter Tig Tecnica TIG 190 DC-LIFT VRD 230V-816219.In the following table, look for the model of the Welding and the respective parts of the code.
| Welding Inverter Tecnica Tig 190 DC-LIFT VRD 230V-816219 Pag.1 | ||
| # | Description | Part Num. |
| 1 | RESISTANCE | 112048 |
| 2 | SINGLE-PHASE RECTIFIER | 112357 |
| 3 | RELAIS | 116320 |
| 4 | DIODE | 116839 |
| 5 | ENCODER | 116959 |
| 6 | RESISTANCE 10R 2W 5% FUSE | 116962 |
| 7 | PWM CONTROLLER | 116966 |
| 8 | POTENTIOMETER KNOB | 121547 |
| 9 | SWITCH | 122381 |
| 10 | MAINS CABLE 3G1.5 2 M SCHUKO PLUG | 132155 |
| 11 | CURRENT TRANSFORMER | 152230 |
| 12 | PULSE TRANSFORMER | 152247 |
| 13 | FAN | 152904 |
| 14 | FILTER INDUCTANCE | 164741 |
| 15 | POWER TRANSFORMER | 169665 |
| 16 | TRANSFORMER X FLYBACK | 169700 |
| 17 | HANDLE SET | 312434 |
| 18 | FRONT PANEL | 322950 |
| 19 | BACK PANEL | 322951 |
| 20 | SOCKET DX 25 | 712000 |
| 21 | BOTTOM KIT | 980345 |
| 22 | KIT IGBT + DIODE | 980614 |
| 23 | COVER KIT | 981103 |
| 24 | COMPLETE PCB KIT | 981104 |
| 25 | CONTROL PCB KIT | 981105 |
| 26 | KEYPAD PCB KIT | 981112 |
| 27 | CONDENSER | 116857 |
| 28 | INDUCTANCE | 169907 |
| 29 | CABLE 16 MMQ 3 M - 25 | 123437 |
| 30 | ARGON GAS BOTTLE IT ADAPTOR | 432036 |
| 31 | TOLEDO 250 WORK CLAMP 250A | 712030 |
| 32 | PLUG DX 25 | 712039 |
| 33 | GAS REGULATOR REFILLABLE BOTTLE | 722341 |
| 34 | ST9V TORCIA TIG 4 M | 722563 |
| Torch Inverter Tecnica Tig 190 DC-LIFT VRD 230V-816219 Pag.2 | ||
| 1 | KIT 10 CERAMIC NOZZLES NR.6 | 802231 |
| 1 | KIT 10 CERAMIC NOZZLES NR.5 | 802229 |
| 1 | KIT 10 CERAMIC NOZZLES NR.4 | 802230 |
| 2 | INSULATING | 722984 |
| 3 | ORING | 722985 |
| 4 | KIT 10 CERIUM-TUNGSTEN ELECTR. D.1,6 MM | 802222 |
| 4 | KIT 10 CERIUM-TUNGSTEN ELECTR. D.1 MM | 802220 |
| 4 | KIT 10 CERIUM-TUNGSTEN ELECTR. D.1,2 MM | 802221 |
| 5 | KIT 3 ELECTRODE HOLDER CLAMPS Ø 1,2 MM | 802224 |
| 5 | KIT 3 ELECTRODE HOLDER CLAMPS D.1,6 MM | 802223 |
| 5 | KIT 3 ELECTRODE HOLDER CLAMPS D.1 MM | 802225 |
| 6 | SHORT CAP | 722982 |
| 7 | LONG CAP | 722981 |
| 9 | CONNECTION KIT 25 | 981442 |
| 15 | HANDLE | 722948 |
| 16 | ORING OR | 722983 |
| 18 | TORCH BODY | 722947 |
| 19 | KIT 3 ELECTRODE DIFFUSERS D.1,6 MM | 802228 |
| 19 | KIT 3 ELECTRODE DIFFUSERS Ø 1,2 MMM | 802226 |
| 19 | KIT 3 ELECTRODE DIFFUSERS D.1 MM | 802227 |
| 20 | LONG CERAMIC NOZZLE NR.4 | 722996 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Telwin websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Telwin brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Tecnica Tig 190 DC LIFT 816219
10 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK ITEM OR S/N CODE TELWIN:
- TELWIN PRODUCT CODE STARTS WITH (8....) AND HAVE 6 DIGITS
