We are STAYER authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair problem for Percussion Drill TH601 - TH601A.
In the following table, look for the model of the Percussion Drill and the respective parts of the code.![]()
| Electricall Drills Stayer TH601 - TH601A | ||
| # | Part Num. | Description |
| 1 | 815930 | DEPTH STOP |
| 2 | 815931 | AUXILIARY HANDLE |
| 3 | 815932 | TAPPING SCREW |
| 4 | 815933 | RIGTH HOUSING |
| 6 | 815934 | CORD SHEATH |
| 7 | 815935 | CORD CLAMPING PLATE |
| 8 | 815936 | CAPACITOR |
| 9 | 815937 | CARBON BRUSH CAP |
| 10 | 815938 | CARBON BRUSH ( 1 PC ) |
| 11 | 815939 | CARBON BRUSH HOLDER |
| 12 | 815940 | SWITCH |
| 13 | 815941 | LEFT HOUSING |
| 14 | 815942 | INESRT OF BUTTON |
| 15 | 815943 | BUTTON |
| 16 | 815944 | STATOR |
| 17 | 815945 | ANTIFRICCION BEARING 626 |
| 18 | 815946 | ROTOR |
| 19 | 815947 | ANTIFRICTION BEARING 608 |
| 20 | 815948 | MIDDLE FRAME ASSEMBLY |
| 21 | 815949 | GEAR |
| 22 | 815950 | STEEL BALL |
| 23 | 815951 | CIRCLIP FOR AXES |
| 24 | 815952 | SPINDLE SLEEVE |
| 25 | 815953 | IMPACT SPRING |
| 26 | 815954 | OUTPUT SPINDLE |
| 27 | 815955 | CHUCK |
| 28 | 815956 | PAN HEAD SCREW |
