In the following table, look for the model of the hammerr and the respective parts of the code.
Stayer HD5CK
Stayer Rotary Hammer SDS-PLUS HD 5 CK
# Part Num. Description
1 8244.88 PROTECTIVE CAP
2 8244.89 PROTECTIVE SLEEVE
3 8244.90 SNAP RING 19×2
4 8244.91 WASHER
5 8244.92 STEEL BALL Φ7.14
6 8244.93 HOLDING PLATE
7 8244.94 SPRING
8 8244.95 WASHER
9 8244.96 SOKET HEAD SCREW M5X30
10 8244.97 SPRING WASHER
11 8244.98 GEAR HOUSING ASSY
11-1 8244.233 GEAR HOUSING
11-2 8244.234 SEAL 41X30X7
11-3 8244.235 BEARING 61906-ZZ
12 8244.99 PAPER WASHER
13-1 A 13-16 8244.455 SET DRILL BUSHING
13-1 8244.100 DRILL BUSHING
13-1 8244.452 SPINDLE
13-2 8244.101 STEEL BALL Φ7.14
13-3 8244.102 O-RING
13-3 8244.453 O-RING
13-4 8244.103 O-RING
13-5 8244.104 IMPACT BOLT
13-6 8244.105 O-RING
13-7 8244.106 RATCHET SLEEVE
13-8 8244.107 O-RING
13-9 8244.108 COMPRESSION SPRING
13-10 8244.109 WASHER
13-11 8244.110 CLUTCH SPRING
13-12 8244.111 SPRING PLATE
13-13 8244.112 CLUTCH SPRING
13-14 8244.113 CLUTCH SLEEVE
13-15 8244.114 CLUTCH
13-16 8244.115 O-RING
14-1 8244.116 STRIKER
14-2 8244.117 O-RING
15-1 8244.118 O-RING
15-2 8244.119 PISTON
15-3 8244.120 PIN
15-4 8244.121 CONNECTING ROD
16 8244.122 BEVEL GEAR
17-1 8244.123 BUSHING
17-2 8244.124 GEAR BOX
17-3 8244.125 SHIFT PLATE 1
17-4 8244.126 SHIFT PLATE 2
17-5 8244.127 SPRING WASHER 4
17-6 8244.128 SOKET HEAD SCREW M4X16
18-1 8244.129 O-RING
18-2 8244.130 OIL CAP
19 8244.131 SCREW ST4.8X50
20-1 8244.132 CRANK SHAFT
20-2 8244.133 BALL BEARING 6203
20-3 8244.134 CIRCLIP 16
21 8244.135 CIRCLIP
22 8244.136 SPRING
23 8244.137 SMALL CLUTCH
24 8244.138 GEAR
25 8244.139 WASHER
26 8244.140 NEEDLE BEARING AXK0816
27-1 8244.141 PINION
27-2 8244.142 BALL BEARING 16002
27-3 8244.143 DISTANCE BUSHING
27-4 8244.144 BIG GEAR
28-1 8244.145 RED BUTTON
28-2 8244.146 SPRING
28-3 8244.147 SELECTOR KNOB
28-4 8244.148 O-RING
29 8244.149 CIRCLIP Φ22
30 8244.150 TRANSFER SHAFT
31 8244.151 BOTTOM COVER ASSY
32 8244.152 ARMATURE ASSY (turn left)
32-1 8244.236 ARMATURE
32 8244.238 ARMATURE WITHOUT RETURN
32-2 8244.237 RODAMIENTO 607 ZZ
33 8244.153 RUBBER BEARING SLEEVE
34 8244.154 AIR-DEFLECTOR RING
35 8244.155 SCREW
36 8244.156 STATOR
37 8244.157 MOTOR HOUSING
38 8244.158 INDUCTOR (with reverse function)
38 8244.239 INDUCTOR 2017 (without reverse function)
39 8244.159 BRUSH HOLDER ASSY NO.1 (with reverse function)
39 8244.241 BRUSH HOLDER ASSY NO.1 2017 (without reverse function)
40 8244.160 SCREW ST3.5×10
41 8244.161 BRUSH HOLDER ASSY NO.2
42 8244.162 CARBON BRUSH (PAIR) (with reverse function)
42 8244.242 CARBON BRUSH 2017 (PAIR) (without reverse function)
43 8244.163 SPRING (with reverse function)
43 8244.243 SPRING 2017 (without reverse function)
44 8244.164 L/R BUTTON
45 8244.165 REAR COVER
46 8244.166 SCREW ST3.9X16 (with reverse function)
46 8244.244 SCREW ST3.9X16 2017   (without reverse function)
47 8244.167 CRANK HOUSING COVER
48 8244.168 DUST COVER
49 8244.169 SPRING
50 8244.170 WASHER
51 8244.171 SPRING PLATE
52 8244.172 WASHER
53 8244.173 BOLT M5X12
54 8244.174 HANDLE
55 8244.175 CONTROLLER
56 8244.176 SWITCH
57 8244.177 CAPACITOR
58 8244.178 CORD CLIP
59 8244.179 CABLE
59 8244.240 CABLE 2017
60 8244.180 CORD GUARD
61 8244.181 SCREW ST5X20
62 8244.182 AUXILIARY HANDLE ASSY
63 8244.183 DEPTH GAUGE
64 8244.184 WASHER
