Stayer Spare Parts for Rotary Hammer HD8K

€5.35
Tax included

Stayer Spare Parts for Rotary Hammer HD8K

We have the original Spares STAYER for Rotary Demolition Hammer HD8K the diagram, parts list and tool repair that help you need to get your tools running like new again.

Fix Your Rotary Demolition Hammer HD8K. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
ITEM CODE: 5002349
Quantity
on 10/15 Business Days Approx

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Stayer Spare Parts for Rotary Hammer HD8K

We have the original Spares STAYER for Rotary Demolition Hammer HD8K the diagram, parts list and tool repair that help you need to get your tools running like new again.

Fix Your Rotary Demolition Hammer HD8K. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following table, look for the model of the hammerr and the respective parts of the code.
Stayer HD8K.

Rotary HAMMER HD8K
# Part Num. Description
1 5002349 FRONT CAP
2 5002350 AXILE CIRCLIP
3 5002351 CIRCLIP
4 5002352 SLIDER
5 5002353 TOOL HOLDER RING
6 5002354 TOOL HOLDER COAT
7 5002355 STEEL BALL
8 5002356 SCREW
11 5002357 TOOL HOLDER
12 5002358 SCREW
15 5002359 SECOND STRIKER
16 5002360 O-RING
17 5002361 CUSHION IRON RING
18 5002362 CUSHION RING
19 5002363 CYLINDER CASE
23 5002365 CYLINDER
24 5002366 RAM
25 5002367 PISTON
26 5002368 PISTON PIN
27 5002369 CONNECTING ROD
28 5002370 NEEDLE BEARING NK12/12
29 5002371 O-RING
30 5002372 TAP BOLT
31 5002373 GREASE UPPER COVER
32 5002374 GREASE NETHER COVER
33 5002375 O-RING
34 5002376 GEAR CASE COVER
35 5002377 O-RING
36 5002378 LEFT SHELL
37 5002379 BIG GEAR
38 5002380 NEEDLE BEARING
39 5002381 BEARING COVER
40 5002382 NUT
41 5002383 ANTI-VIBRATION SPRING
42 5002384 ANTI-VIBRATION WASHER
43 5002385 ANTI-VIBRATION BOLT
44 5002386 HANDLE CAP
45 5002387 O-RING
46 5002388 NUT
47 5002389 LEFT HANDLE
48 5002390 NUT
49 5002391 GEAR CASE
50 5002392 OIL SEAL
51 5002393 BEARING 6201-RS
52 5002394 SKIDPROOF POLE
53 5002395 ROTOR
54 5002396 INSULATION RING
55 5002397 AIR BAFFLE
56 5002398 SCREW
57 5002399 STATOR
58 5002400 BEARING 6000
59 5002401 MOTOR HOUSING
60 5002402 RUBBER COVER
61 5002403 SCREW
62 5002404 BRUSH HOLDER
63 5002405 CARBON BRUSH SET
64 5002406 BRUSH HOLDER CAP
65 5002407 SCREW
66 5002408 MOTOR HOUSING BOTTON COVER
67 5002409 TAP BOLT
68 5002410 RIGHT SHELL
69 5002411 ANTI-VIBRATION COVER
70 5002412 SCREW
71 5002413 RIGHT HANDLE
72 5002414 TAP BOLT
73 5002415 SWITCH
77 5002416 INDUCTANCE
78 5002417 CABLE CLAMP

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Stayer websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Stayer brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
