Milwaukee PH30POWERX Comby Hammer Parts

€2.33
Tax included

Milwaukee PH30POWERX Comby Hammer Spare Parts

Fix Your Milwaukee PH30POWERX Comby Hammer. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
Milwaukee PPH30QEX/ASK Rotary Hammer
ITEM CODE: 4931624616
Quantity
Usually Ships in: 7/10 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Milwaukee PH30POWERX Comby Hammer Spare Parts

Fix Your Milwaukee PH30POWERX Comby Hammer. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following table, look for the model of the Drill Driver and their spare part.
Milwaukee PH30POWERXRotary Hammer
Milwaukee PH30X 240V SDS PLUS COMBI HAMMER IN2 Spare Parts
4933396420 - PH30POWERX - 4000396421
# Part Num. Description
3 4931624616 SCREW
4 4931623857 CONNECTION CABLE
5 4931393422 PROTECTING COVER
6 4931624581 SCREW
8 4931455681 RATING PLATE
100 4931396317 MOTOR HOUSING
105 4931442731 ELECTRIC FIELD
106 4931442664 ARMATURE
107 4931396544 slinger sleeve - Discontinued
108 4931396535 GROOV. BALL BEARING - Discontinued
109 4931396325 BEARING COVER
110 4931342793 FAN
111 4931396442 INSULATING DISC
112 4931902888 BALL BEARING
113 4931396534 AIR DEFLECTOR RING
117 4931396546 SET COLLAR
123 4931342808 CENTERING LEDGE
127 4931624515 SCREW N874101-1 SHR H-K4X18 T15
135 4931621772 SCREW
136 4931487441 SPEED GOVERNOR
137 4931396368 SLIDER
141 4931256500 CABLE COLLAR
143 4931624538 SCREW
150 4931396450 HANDLE SET
200 4931396375 GEAR BOX
201 4931396305 GEAR BOX
202 4931331760 NEEDLE BUSH
203 4931396373 BEARING
204 4931933756 NEEDLE BEARING N874989 HK 0709
205 4931396432 PRESSURE SPRING
206 4931396385 LOCKING PLATE
207 4931396462 SCREW
208 4931396314 BEARING END PLATE
209 4931365112 WASHER
210 4931396336 CYLINDRICAL BOLT
211 4931396541 CYLINDER
212 4931455431 PERCUSSION BODY
213 4931396548 THRUST COLLAR
214 4931409779 SLEEVE
215 4931396428 SNAP DIE
216 4931396427 STOP WASHER
225 4931409754 RING STOP
226 692737001 PRESSURE SPRING
227 4931624257 WASHER
228 4931805437 BALL
230 4931417458 SPINDLE SLEEVE
234 4931624457 WASHER
237 4931396339 CLUTCH DISC
239 4931624639 WASHER
330 4931384684 ADAPTER
331 4931409763 ADAPTER
333 4931622874 SPRING RING
334 4931384681 SET SLEEVE
335 4931321064 SPRING
336 4931911572 BALL
337 4931343034 JUMPER RING
338 4931343057 SPACER
339 4931805413 BALL
340 4931396444 REDUCT. GEAR SHAFT
341 4931375873 SPROCKET
343 4931417721 REDUCT. GEAR SHAFT
344 4931375874 INTERN.GEARED WHEEL
346 4931396545 PRESSURE SPRING
347 4931396329 COUPLING SLEEVE
348 4931396522 WOBBLE DRIVE
349 4931426238 REDUCTION GEAR
350 4931396369 DISTANCE SLEEVE
351 4931624678 SCREW
352 4931624471 CYLINDER PIN
353 4931396384 SLIDING SWITCH
354 4931396347 SWITCH HANDLE
370 4931396400 HOLDING-DOWN DEVICE
444 4931407935 SPINDLE SLEEVE
602 4931302074 RING SPRING
604 4931392452 CHUCK ADAPTER
605 4931384434 DEPTH GAUGE
700 4931415325 CARRYING CASE
705 4931392747 HANDLE
1200 4931396419 MAINTENANCE SET
1201 4931396547 CARBON BRUSH SET
1202 4931396532 RUBBER SLEEVE
1203 4931396445 SLEEVE
1204 4931945764 SPRING RING
1206 4931624259 SEAL RING D 3760 AS 22X35X7
1207 4931623961 SEAL RING
1208 4931396374 SEAL
1210 4931396461 SEAL RING
1212 4931623636 RING
1213 4931454456 O-RING
1214 4931396459 SEAL RING
1215 4931384919 SPRING RING
1217 4931624476 SEAL RING
1219 4931624493 SEAL RING
1220 562578001 HOLDING-DOWN DEVICE
1222 4931624260 SPRING RING
1226 4931387563 FELT
1228 4931332524 HOLDING-DOWN DEVICE
1230 4931624381 O-RING N874701 25X2
1300 4931432150 REPAIR KIT
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Milwaukee websites, which we consider as reliable.Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice.We strongly recommend using the published information as a basic information subject to Milwaukee brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
