Metabo Spare Parts for Sander for Walls and Ceilings LSV 5-225

€1.58
Tax included

Metabo Spare Parts for Sander for Walls and Ceilings  LSV 5-225

Metabo genuine spare parts for to fix Wall and Ceilings Sander LSV 5-225/00103000.

Wall and Ceilings Sander LSV 5-225
ITEM CODE: 14111054
Quantity
on 10 Business Days Approx

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Metabo Spare Parts for Sander for Walls and Ceilings LSV 5-225

Metabo genuine spare parts for to fix Wall and Ceilings Sander LSV 5-225/00103000.

In the following table, look for the model of the Sander and the respective parts of the code.
Metabo LSV 5-225 - 00103000

Sander for Walls and Ceilings LSV 5-225/00103000
# Part Num. Description
1 34410176 Damping ring
2 34343777 Brush holder module
3 31604690 Carbon brush set cut-off
4 14115595 Washer
5 14111990 Self-tapp. fill. h. screw
6 31101232 Field coil w.field coil,230V
7 14112410 Fillister head screw
8 34343778 Motor flange
9 14111826 Self-tap. fill. h. screw
10 34409787 Rubber bushing
11 14311475 Ball bearing, 6X 19X 6
12 31001159 Armature compl.,230V
13 14311506 Ball bearing, 8X 22X 7
14 31520293 Flange
15 33901214 Gear gasket
16 14111054 Fillister head screw
17 34409142 Rubber plug
18 31606307 Gear-box cover cpl.
19 31606308 Intermediate shaft, cpl.
20 33901213 Gear gasket
21 31606309 Intermediate flange cpl.
23 34000437 Internal gear
24 31606310 Planet carrier cpl.
25 14311545 Needle roller and cage
26 34000438 Planet wheel
30 14111602 Self-tap fill h screw
31 33806529 Rating plate 00103000 LSV 5-225
43 34343768 Extraction channel
44 34336249 Cable clip
45 14111706 Self-tap. fill. h. screw
46 34410114 Cable sleeve
48 34341083 On-off switch
50 34305014 Terminal rail
51 34453049 Strand compl.
53 34308513 Electronic unit,230V 55/60Hz
55 34449318 Cable with plug
58 14111318 Self-tap. fill. h. screw
60 31606200 Hollow shaft compl.
63 34410166 plastiv insert
64 34111289 Retaining tube
68 14115011 Washer
77 14118004 Retaining ring
78 14311112 Ball bearing, 10x26x8
79 34160482 Intermediate shaft
80 34107177 Retainer bushing
81 14115636 Circlip
82 31606203 Extraction hose compl.
83 34343779 Holder compl.
84 14111105 Cap screw
85 34343860 Cover
86 34343861 Cover
87 34343776 Fork compl.
88 34343782 Swivel flange compl.
89 34100629 Sliding bushing
90 14111613 Self-tap. fill. h. screw
98 34343771 bearing clamp
99 34100628 Sliding bushing
100 34343783 Wheel guard
101 34100627 Sliding bushing
102 34343772 Covering hood
103 34343773 Angle bracket
104 31606312 Adjusting ring cpl.
105 34343769 Edge protection
106 34410174 Sealing lip
108 34343828 Brush holder
110 31606201 round compl.
111 14115194 Washer
112 14111384 Cap screw
114 34500017 Flexible shaft
115 31606311 Gear Cover
117 31606239 connecting sleeve
118 34343839 Plug
119 34343840 Plug
880 34413093 Grease 50Gr 1,8oz
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Metabo websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Metabo brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Metabo LSV 5-225 - 00103000
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10 BUSYNESS DAYS APPROX.
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N METABO:
METABO S/N START WITH ( 0 ) and have 8 DIGITS
New

Download

Diagram Metabo LSV 5-225

Diagram Metabo LSV 5-225

Download (856.23KB)
