Metabo Hammer KHA 18 LTX Parts
€3.21
Tax included
Metabo Parts for Cordless Rotary Hammer Drill KHA 18 LTX
Metabo genuine spare parts or replacement parts for to repair Cordless SDS-Plus Rotary Hammer Drill 00210000 KHA 18 LTX 18v SDS-PlusFix Your Cordless SDS-Plus Rotary Hammer Drill KHA 18 LTX. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Metabo Parts for Cordless Rotary Hammer Drill KHA 18 LTX
Metabo genuine spare parts or replacement parts for to repair Cordless SDS-Plus Rotary Hammer Drill 00210000 KHA 18 LTX 18v SDS-Plus
Fix Your Cordless SDS-Plus Rotary Hammer Drill KHA 18 LTX. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the Cordless Hammer Drill and the respective parts of the code.
| METABO 00210000 KHA 18 LTX 18v | ||
| # | Part Num | Description |
| 1 | 34409939 | Rubber cap |
| 2 | 34202234 | Circlip |
| 3 | 34343292 | Adjusting ring |
| 4 | 33900765 | Washer |
| 5 | 34200389 | Pressure spring |
| 6 | 14311533 | Ball |
| 7 | 31605295 | Gear housing compl. |
| 8 | 34170481 | Screw |
| 9 | 34101321 | Supporting disc |
| 10 | 14118129 | Circlip |
| 11 | 34207034 | Cup spring |
| 12 | 33900487 | Friction washer |
| 13 | 34000409 | Spur gear |
| 14 | 33900638 | friction slice |
| 15 | 34105923 | coupling sleeve |
| 16 | 31605303 | Drill driving sleeve compl. |
| 17 | 34121061 | Piston |
| 18 | 34116156 | O-ring, 11.9X2.62 |
| 19 | 34121060 | Damping ring |
| 20 | 14319464 | O-ring |
| 21 | 34105931 | Catching sleeve |
| 22 | 14319392 | O-ring |
| 23 | 14118184 | Circlip |
| 24 | 34409314 | Sealing ring |
| 25 | 31604801 | Striker compl. |
| 26 | 34121080 | exciter sleeve compl. |
| 27 | 34202235 | sealing ring |
| 28 | 31605304 | Gear flange compl. |
| 29 | 34407067 | Felt seal |
| 30 | 34409592 | Rubber buffer |
| 32 | 14311530 | Thrust washer |
| 33 | 14311550 | Axial needle bearing |
| 34 | 31606108 | Intermediate gear compl. |
| 35 | 14115492 | Cup spring |
| 36 | 33900768 | Washer |
| 37 | 31605299 | Control knob compl. |
| 38 | 34339834 | Seal |
| 39 | 31604561 | Shift element compl. |
| 40 | 31604570 | safety clutch cpl. |
| 41 | 34151163 | Depth stop |
| 42 | 31400114 | Side support handle compl. |
| 43 | 34339831 | Sealing washer |
| 44 | 14311589 | Ball bearing, 8X 22X 7 |
| 45 | 31001130 | Armature |
| 46 | 31606109 | Armature compl. |
| 47 | 31101188 | Field coil compl., 2 pol. |
| 48 | 34409874 | Rubber bushing |
| 49 | 39999999 | Part not needed |
| 50 | 31605321 | Brush holder compl., 18 V |
| 51 | 34341057 | Switch slide |
| 52 | 34344014 | Press button |
| 53 | 34308338 | LED lense |
| 54 | 34344015 | Pressure plate |
| 55 | 34200177 | Pressure spring |
| 56 | 33914751 | hook |
| 57 | 34344013 | Motor housing |
| 58 | 34344016 | Cover left |
| 59 | 34170471 | Screw, ST2,9x13 |
| 60 | 34308445 | Electronic switch |
| 61 | 34341056 | Switch slide, R+L |
| 62 | 14111602 | Self-tap fill h screw |
| 63 | 34344017 | Cover right |
| 64 | 33812994 | Indication label |
| 65 | 31606107 | Maintenance kit |
| 66 | 14111602 | Self-tap fill h screw |
| 67 | 33806259 | Rating plate |
| 68 | 14311601 | Ball bearing, 5X 13X 4 |
| 95 | 34343968 | Cover cap |
| 880 | 34413080 | Grease FG 126 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Metabo websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Metabo brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
METABO KHA18LTX - 00210000
6 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N METABO:
- METABO S/N START WITH ( 0 ) and have 8 DIGITS
