Metabo Spare Parts for Paint Remover LF 724 S
search
  • Metabo Spare Parts for Paint Remover LF 724 S
  • Metabo Spare Parts for Paint Remover LF 724 S

Metabo Spare Parts for Paint Remover LF 724 S

€1.84
Tax included

Metabo Spare Parts for Paint Remover LF 724 S

Metabo original spare parts for to replace broken parts for to fix Paint Remover LF724S - 00724000.

Only from Metabo: the problem solver for renovation work. Saves up to 70% of time when compared to conventional working methods
Paint Remover LF 724 S - 00724000
ITEM CODE: 14111059
Quantity
Usually Ships in: 10 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Metabo Spare Parts for Paint Remover LF724S

Metabo original spare parts for to replace broken parts for to fix Paint Remover LF724S - 00724000.

Open PDF Diagram, check your spare part number position and then select it in the following table.
Paint Remover LF 724 S - 00724000

Paint Remover LF 724 S
# Part Num. Description
2 34111254 HANDLE COVER COMPL.
3 34170149 Tight-fit screw
4 31602873 Gear housing cpl.
5 14112176 Countersunk screw
6 34110094 Hexagon nut w.recess
7 31601815 Bevel gear
8 33900681 Washer
9 14311488 Ball bearing, 8x22x7
10 34160362 Bush
11 31000814 Armature cpl.230V
12 14311566 Ball bearing, 6x19x6
13 34409526 Rubber bushing
14 14115334 Washer
15 34339418 Switch slide
16 34337364 Switch rod
17 14111699 Self-tap. fill. h. screw
18 34337441 Housing with cover
19 34410114 Cable sleeve
20 33812216 M-Label,08 52x22
21 31603550 Brush holder cpl.
22 34449396 Cable strand
23 14111602 Self-tap fill h screw
24 34336249 Cable clip
25 33915093 Baffle
26 31100996 Field coil 230V
27 33804093 Rating plate
28 31501268 Motor housing
29 34449395 Strand
30 34449397 Strand
31 34340673 Switch
32 34337442 Housing with cover
33 34449318 Cable with plug
34 33812125 Indication label
35 34110138 Nut
36 34207035 Cup spring
37 14115230 Washer 10,2 X 14,8X 0,1
38 14115112 Washer 10,2 X 14,8X 0,2
39 34207032 Cup spring
40 33903279 Friction washer
41 33903415 Friction washer
42 34105148 Intermediate piece
43 33919063 Bearing cover
44 14311388 Ball bearing, 10x26x8
45 33900401 Washer
46 34407023 Felt ring
47 33906016 Compensating Washer
48 14111987 Fillister head screw
49 34160350 Spindle
50 31602894 Safety clutch
51 34170280 Adjusting screw
52 34170290 Flat headed screw
53 63166000 Revers.solid tungsten carb.blades(10pcs)
54 34170281 Countersunk screw
55 34207055 Cup spring
56 31602677 KNIFE HOLDER COMPL.
57 14111986 Fillister head screw
58 34337406 Protecting cap
59 34200268 Pressure spring
60 34152004 Pin
61 34337138 Extraction cover
62 14111059 Fillister head screw
63 31602895 Table cpl.
64 34337139 Exhaust nozzle
65 34416254 Pick w. handle
66 34416245 Universal spanner
67 34339419 Push button, red
68 34200155 Pressure spring
69 33900652 Sealing washer
70 34151379 Bolt
72 31603551 Carbon brush
880 34413056 Grease SF 011 50Gr 1,8oz
882 34413084 Special grease 100Gr 3,6oz
