Metabo Spare Parts for Combination Hammer KHE 56
We are METABO original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Combination Hammer KHE 56 - 00340000.In the following table, look for the model of the Drill and the respective parts of the code.
| Combination Hammer KHE 56/00340000 | ||
| # | Part Num. | Description |
| 1 | 34339440 | Control knob |
| 2 | 34409809 | O-ring |
| 3 | 14112356 | Fillister head screw |
| 4 | 31541632 | Gear-box cover |
| 5 | 34409825 | Rubber cap |
| 6 | 34339441 | Sliding sleeve compl. |
| 7 | 14115545 | Circlip |
| 8 | 34101293 | Washer |
| 9 | 34409813 | O-ring |
| 10 | 34105867 | Sleeve |
| 11 | 34101294 | Washer |
| 12 | 33913329 | Guide sheet |
| 13 | 34200351 | Pressure spring |
| 14 | 33913331 | Guide plate |
| 15 | 14115634 | Retaining ring |
| 16 | 31604270 | Holder compl. |
| 17 | 34107059 | Ring |
| 18 | 34003281 | Bevel gear |
| 19 | 34339439 | Setting ring |
| 20 | 33913318 | Retaining sheet |
| 21 | 34409817 | O-ring |
| 22 | 31604262 | Piston compl. |
| 23 | 31604258 | Clutch |
| 24 | 34101295 | Washer |
| 25 | 32005064 | Needle roller and cage |
| 26 | 34409824 | Rubber ring |
| 27 | 34101289 | Supporting disc |
| 28 | 33913332 | Carrier |
| 29 | 34105866 | Drill driving sleeve |
| 30 | 34101296 | Brake ring |
| 32 | 31604266 | Piston compl. |
| 33 | 34101286 | Stop ring |
| 34 | 34409826 | Rubber ring |
| 35 | 34101287 | Stop ring |
| 36 | 34202209 | Circlip |
| 37 | 31604261 | Striker compl. |
| 38 | 34101288 | Washer |
| 39 | 31604260 | Spindle compl.,SDS-M |
| 40 | 33812109 | Metabo label |
| 41 | 34339434 | GEAR BOX CAP |
| 42 | 34339443 | Pressure plate |
| 43 | 34200352 | Pressure spring |
| 44 | 34409823 | Seal |
| 45 | 33913322 | Retaining sheet |
| 46 | 14112358 | Fillister head screw |
| 47 | 31604259 | Bevel gear compl. |
| 48 | 34101291 | Washer |
| 49 | 34151531 | Bearing bolt |
| 50 | 32005068 | Bearing |
| 51 | 31510473 | Gear housing compl. |
| 52 | 31604265 | Carbon brush set |
| 53 | 33901165 | Shaft sealing ring |
| 54 | 34449740 | Lead Wire (Switch) |
| 55 | 33804933 | NAME PLATE |
| 56 | 34409809 | O-ring |
| 57 | 34339432 | Motor cap cpl. |
| 58 | 14112355 | Fillister head screw |
| 59 | 33000187 | Fan |
| 60 | 31000931 | Armature compl.,220-240 V |
| 61 | 34409807 | Dust seal |
| 62 | 32005065 | Ball bearing |
| 63 | 34339431 | Tacho disc |
| 64 | 34409822 | Rubber bushing |
| 65 | 34170427 | Screw,L5x35 T2025 |
| 66 | 34339433 | Handle 2 part |
| 67 | 34339429 | Cover cap |
| 68 | 34409808 | Sealing ring |
| 69 | 34202207 | Retaining ring |
| 70 | 32005067 | Ball bearing |
| 71 | 31530063 | Gear cover |
| 72 | 31604252 | Armature w.flange |
| 73 | 33901164 | Damping ring |
| 74 | 34308135 | Electronic unit,220-240 V |
| 75 | 34339435 | Pressure plate |
| 77 | 34340767 | On-off switch |
| 78 | 34339438 | Light transmitter |
| 79 | 33915111 | Baffle |
| 80 | 34170421 | Screw,4x64 |
| 81 | 31101085 | Field coil w.field coil,220-240 V |
| 82 | 31501326 | Motor housing |
| 84 | 14112354 | Fillister head screw |
| 85 | 34170424 | Screw, |
| 86 | 34300092 | Brush holder |
| 87 | 34170424 | Screw, |
| 88 | 34339421 | Cable clip |
| 89 | 34409821 | Cable sleeve |
| 90 | 34449743 | Cable w.CEE plug |
| 91 | 33913319 | Clamping holder |
| 92 | 14113102 | Square nut |
| 93 | 34170422 | Screw,K5x45 T20 |
| 94 | 31604254 | Body compl. |
| 95 | 31400108 | Side support handle compl. |
| 96 | 31400107 | Anti-vibration handle compl. |
| 97 | 33105075 | Depth stop |
| 98 | 31604263 | Shift element compl. |
| 99 | 31604264 | Maintenance kit |
| 100 | 34170426 | Screw, |
| 880 | 34413117 | Tube Grease,45 g Urethyn |
