Metabo Spare Parts for Combination Hammer KHE 96
€1.58
Tax included
Metabo Spare Parts for Combination Hammer KHE 96
Metabo service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues fo Combination Hammer KHE 96 - 00596000.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Metabo Spare Parts for Combination Hammer KHE 96
Metabo service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues fo Combination Hammer KHE 96 - 00596000.In the following table, look for the model of the Hammer and the respective parts of the code.
| Combination Hammer KHE 96/00596000 | ||
| # | Part Num. | Description |
| 1 | 34409797 | Rubber cap |
| 2 | 34339428 | Sleeve |
| 3 | 14115545 | Circlip |
| 4 | 34101285 | Ring |
| 5 | 34409798 | Damping ring |
| 6 | 34105865 | Sleeve |
| 7 | 33900708 | Carrier |
| 8 | 33913317 | Intermediate plate |
| 9 | 34200348 | Pressure spring |
| 10 | 34101292 | Washer |
| 11 | 14111404 | Cap screw |
| 12 | 33913276 | Retaining ring |
| 13 | 34409814 | O-ring |
| 14 | 33901162 | Shaft sealing ring |
| 15 | 14118045 | Retaining ring |
| 16 | 34339425 | Control knob |
| 17 | 34409809 | O-ring |
| 18 | 14112357 | Cap screw |
| 19 | 14115002 | Washer |
| 20 | 31541590 | Gear-box cover |
| 21 | 34409805 | Seal |
| 22 | 33913315 | Shift fork |
| 23 | 33913316 | Retaining sheet |
| 24 | 34339427 | Setting ring |
| 25 | 31604244 | Piston compl. |
| 26 | 34409818 | O-ring |
| 28 | 32005063 | Bearing |
| 30 | 31604247 | Maintenance kit |
| 31 | 31510470 | Gear housing compl. |
| 32 | 31604208 | Side support handle compl. |
| 33 | 34202208 | Circlip |
| 34 | 34107058 | Ring |
| 35 | 34101284 | Ring |
| 36 | 34107057 | Supporting disc |
| 37 | 34409819 | O-ring |
| 38 | 33900694 | Stop ring |
| 39 | 34105863 | Drill driving sleeve |
| 40 | 34409815 | O-ring |
| 41 | 31604242 | Piston compl. |
| 42 | 34101282 | Stop ring |
| 43 | 34409804 | Ring,NBR |
| 44 | 34101283 | Stop ring |
| 45 | 34105864 | Pin |
| 46 | 34105862 | Sleeve |
| 47 | 31604243 | Striker compl. |
| 48 | 31604241 | Spindle compl.,SDS-M |
| 49 | 34409806 | Felt seal |
| 50 | 34409811 | O-ring |
| 51 | 34339234 | Housing cover compl. |
| 52 | 33915109 | Baffle |
| 53 | 34339423 | Pressure plate |
| 54 | 34200347 | Pressure spring |
| 55 | 34339424 | Bevel gear |
| 56 | 33804941 | Rating plate |
| 57 | 31604248 | Carbon brush set |
| 58 | 34170424 | Screw, |
| 59 | 34409816 | O-ring |
| 60 | 34300092 | Brush holder |
| 61 | 34449740 | Lead Wire (Switch) |
| 62 | 33913275 | Cover |
| 63 | 34170423 | Screw,C-K6x16 T25 |
| 64 | 34170425 | Screw, |
| 66 | 34339422 | Handle 2 part |
| 69 | 34340767 | On-off switch |
| 71 | 33000186 | Fan |
| 72 | 32005065 | Ball bearing |
| 73 | 31604815 | Armature compl. ,220-240 V+Bevel gear |
| 74 | 34409803 | Sealing ring |
| 75 | 34202207 | Retaining ring |
| 76 | 32005067 | Ball bearing |
| 77 | 31530062 | Gear cover |
| 78 | 31604816 | Armature w.flange,220-240 V+Bevel gear |
| 79 | 33812120 | Indication label,KHE 96 |
| 80 | 34339426 | Blank faceplate |
| 81 | 14112358 | Fillister head screw |
| 82 | 31400105 | Anti-vibration handle compl. |
| 83 | 34409802 | Rubber bushing |
| 84 | 31101083 | Field coil w.field coil,220-240 V |
| 85 | 34170421 | Screw,4x64 |
| 86 | 34170422 | Screw,K5x45 T20 |
| 87 | 33812111 | Metabo label |
| 88 | 34409812 | O-ring |
| 89 | 34308131 | Electronic unit,220-240 V |
| 90 | 34339421 | Cable clip |
| 91 | 34409801 | Cable sleeve |
| 92 | 34449743 | Cable w.CEE plug |
| 95 | 31604819 | Clutch + Bevel gear |
| 96 | 32005064 | Needle roller and cage |
| 97 | 31604209 | Motor housing compl. |
| 98 | 31604316 | Washers set |
| 880 | 34413117 | Tube Grease,45 g Urethyn |
| 885 | 34413116 | Tube Grease,Gadus S5V220 |
