Maruyama Vacuum Kit BL3100 Parts

€91.78
Tax included

Maruyama Parts for Vacuum Kit BL3100

Fix Your Maruyama Vacuum Kit BL3100. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
ITEM CODE: 281535
Quantity
Usually Ships in: 10/15 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Maruyama Parts for Vacuum Kit BL3100

Fix Your Maruyama Vacuum Kit BL3100. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following tables, look for the spare part and its respective code.
Vacuum Kit BL3100

Maruyama Vacuum Kit BL3100 Parts
Main Body Pag.1
# Part. Num. Description
1-1 395754 BL3100
1-2 858117 Engine
1-3 281535 Fan Case
1-4 281586 Stopper (A)
1-5 281867 Stopper (B)
1-6 282862 Washer
1-7 269423 Nut
1-8 126993 Nut
1-9 261246 Cap Screw
1-10 281880 Grip (B)
1-11 281865 Stand
1-12 281862 Cable Comp.
1-13 281585 Lever
1-14 282170 Switch Ass'y Incl.15-18
1-15 281863 Switch
1-16 282028 Label
1-17 282172 Screw
1-18 282171 Knob
1-19 281536 Fan Cover
1-20 281869 Plate
1-21 280008 Nut
1-22 282060 Tapping Screw
1-23 281563 Cover
1-24 281870 Spring
1-25 281878 Rod
1-26 263743 Washer
1-27 281871 Screw
1-28 281989 Tapping Screw
1-29 281873 Washer
1-30 281874 Fan
1-31 283041 Nut
1-32 261250 Cap Screw
1-33 281538 Handle
1-34 281879 Grip (A)
1-35 281989 Tapping Screw
1-36 260459 Label
1-37 266959 Label
1-38 266957 Label
1-39 283206 Label
1-40 286308 Label
Engine Pag.2
2-1 858117 Engine
2-2 282400 Cylinder
2-3 282537 Gasket
2-4 261250 Cap Screw
2-5 282579 Insulator
2-6 281590 Air Duct
2-7 261171 Gasket
2-8 265924 Cap Screw
2-9 282585 Muffler Ass'y Incl.35,36
2-10 282586 Muffler Comp.
2-11 281860 Tail
2-12 267056 Spark Arrester
2-13 265107 Cap Screw
2-14 268461 Holder
2-15 281589 Gasket
2-16 266713 Cap Screw
2-17 261607 Cap Screw
2-18 283054 Top Cover
2-19 281989 Tapping Screw
2-20 265724 Cap Screw
2-21 268241 Crankcase
2-22 261491 Bearing
2-23 261492 Oil Seal
2-24 261386 Oil Seal
2-25 055185 Snap Ring
2-26 261612 Cap Screw
2-27 281442 Screen
2-28 268782 Piston
2-29 265067 Piston Ring
2-30 265068 Piston Pin
2-31 265225 Bearing,Needle
2-32 261393 Clip,Piston Pin
2-33 265141 Crankshaft/Conn.Rod Ass'y
2-34 282217 Magneto Ass'y
2-35 269808 Rotor/Fan
2-36 282010 Ignition Coil Ass'y
2-37 261076 Woodruff Key
2-38 281872 Shaft
2-39 280381 Spacer
2-40 261256 Cap Screw
2-41 262483 Spark Plug
2-42 281864 Lead
2-43 282087 Lead
2-44 281172 Grommet
2-45 283204 Label
2-46 282757 Starter Ass'y Incl.47-54
2-47 280492 Reel
2-48 280493 Spiral Spring
2-49 280494 Screw
2-50 283616 Starter Rope
2-51 282186 Starter Grip
2-52 282187 Stopper
2-53 280547 Washer
2-54 269423 Nut
2-55 269492 Starter Pulley Ass'y
2-56 265724 Cap Screw
Carburetor - Fuel Tank Pag.3
3-1 282528 Carburetor Ass'y Incl.2-18
3-2 264155 Pump Body
3-3 262991 Purge Body
3-4 262992 Cover Plate
3-5 261874 Primer Bulb
3-6 283905 Diaphragm, Meterring
3-7 262993 Gasket
3-8 262994 Diaphragm,Fuel Pump
3-9 282576 Gasket
3-10 261876 E-Ring
3-11 261658 Swivel
3-12 261875 Screw
3-13 264677 Bracket
3-14 261878 Nut
3-15 261877 Adapter
3-16 261657 Packing
3-17 262996 Screw
3-18 264678 Washer
3-19 282578 Gasket
3-20 268055 Air Filter Case Ass'y Incl.21-24
3-21 268056 Air Filter Case
3-22 268057 Valve
3-23 268412 Sleeve
3-24 268157 Sleeve
3-25 263345 Packing
3-26 263942 Washer
3-27 263815 Stay
3-28 264016 Cap Screw
3-29 265026 Screen
3-30 281861 Element
3-31 268058 Air Filter Cover Ass'y Incl.32-34
3-32 268059 Air Filter Cover
3-33 281438 Knob
3-34 261734 Snap Ring
3-35 283220 Fuel Tank Ass'y Incl.36-46
3-36 281587 Fuel Tank
3-37 281564 Fuel Tank Cap Ass'y Incl.38
3-38 269377 Gasket
3-39 282538 Fuel Pipe Pick-up Ass'y Incl.40-46
3-40 282539 Fuel Pipe Ass'y Incl.41-44
3-41 282540 Pipe & Grommet
3-42 261690 Fuel Pipe
3-43 261590 Breather
3-44 261117 Clip
3-45 264653 Filter Ass'y
3-46 261117 Clip
3-47 261117 Clip
3-48 268940 Screw
3-49 281715 Cap Screw
3-50 261352 Label
Accessories Pag.4
4-1 281875 Pipe (A)
4-2 281876 Pipe (B)
4-3 282738 Tool Set Incl.4,5
4-4 219431 Wrench
4-5 210418 Box Spanner
4-6 283285 Instruction Manual
4-7 283312 Instruction Manual
4-8 522293 Parts List
