Makita Spare Parts for Dustless Cutter Dry Cutting 4105KB

€14.77
Tax included

Makita Spare Parts for Dustless Cutter Dry Cutting 4105KB

MAKITA Original spare parts at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly resolve any maintenance or repair issues for Dustless Cutter Dry Cutting Ø 125mm 4105KB.
ITEM CODE: 155463-6
Quantity

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Makita Spare Parts for Dustless Cutter Dry Cutting 4105KB

MAKITA Original spare parts

 at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly resolve any maintenance or repair issues for Dustless Cutter Dry Cutting Ø 125mm 4105KB.

In the following table, look for the model of Dustless Cutter and the respective parts of the code.
Makita 4105KB

Dustless Cutter Dry Cutting 4105KB
# Part Num. Description
1 251812-6 SCREW M5x10
2 155463-6 BLADE COVER
3 265226-3 HEXAGON BOLT M6X17
4 224081-2 EXTERNAL FLANGE
5 911133-5 SCREW M4X18
7 224080-4 INTERNAL FLANGE 36
8 315360-0 CAP BLADE
9 321383-8 TREE
10 254011-9 KEY CRESCENT 4
11 253335-0 WASHER 12
12 211129-9 BALL BEARING 6201DDU
13 962151-6 RETAINING RING R32
14 221692-4 GEAR 40
15 961052-5 RETAINING RING S12
16 212028-8 ROLLER BEARING 709
17 411301-5 BACK
18 122191-8 BAG
19 262018-1 RUBBER RING 26
20 942151-2 WASHER 6
21 934301-3 WING NUT M6
24 911263-2 HEAD SCREW M5x40
25 156300-7 HOUSING MOTOR
26 181030-1 CARBON BRUSHES CB-100 (101,2,3)
27 643600-9 PLUG BRUSH HOLDER
28 522533-0 STATORE
29 411902-9 AIR CONVEYOR
30 263002-9 PIN RUBBER 4
31 210005-4 BALL BEARING 608 DDW
32 681613-2 INSULATION WASHER
33 512923-5 ARMATURE
34 241636-8 FAN 72
35 961052-5 RETAINING RING S12
36 253748-5 FLAT WASHER 12
37 211131-2 BALL BEARING 6001DDW
38 263002-9 PIN RUBBER 4
39 685700-9 SPONGE
40 682504-0 CABLE SLEEVE 10/85
42 687001-1 CLAMP cable tie
43 911133-5 SCREW M4X18
44 155919-9 COVER HANDLE
45 421142-1 SWITCH COVER
46 651204-3 SWITCH
47 645006-7 CAPACITOR X LS1013
48 951222-4 JACK BAND 6/36
49 168089-5 BASE
50 251919-8 SCREW M6X20
51 157540-0 CARCASS INGRAN.X 4105KB
52 911111-5 SCREW M4X10
53 162097-8 SEPARATOR
54 911143-2 SCREW M4X22
56 652603-2 SALVAMOTORE
57 410192-1 COVER ENGINE UM3000 / 84D

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s MAKITA websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to MAKITA brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
