at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly resolve any maintenance or repair issues for Mixer UT1400.
In the following table, look for the model of the Mixers and the respective parts of the code.![]()
| Mixer Makita UT1400 | ||
| # | Part Num. | Description |
| 1 | 80900093 | BACK COVER |
| 2 | 80201267 | SCREW 4,8X45 |
| 3 | 7731C100 | ARMATURE |
| 4 | 80410011 | BEARING 608 2Z |
| 5 | 80201333 | RING 28 / 1.2 |
| 6 | 80201196 | BRUSHES HOLDER |
| 7 | 7132A22S | CARBON BRUSHES X DBM080 (2PCS) |
| 8 | 80201385 | WASHER B4 |
| 9 | 80201180 | SCREW M4X12 |
| 11 | 80201305 | RING 10/1 |
| 12 | 83000036 | RING 22X2,5 |
| 13 | 80201449 | SCREW 50X50 |
| 14 | 80410031 | BEARING 6001 2Z |
| 15 | 77318610 | HOLDER |
| 16 | 77M21400 | GEAR BOX |
| 17 | 74010470 | GEAR |
| 18 | 7731C490 | POST |
| 21 | 80410043 | BEARING 6003 2RS |
| 22 | 7731C420 | POST THREAD |
| 24 | 80410130 | BEARING 6203 2RS |
| 25 | 7731C430 | GEAR |
| 26 | 80200507 | WASHER 17 / 24X0,2 |
| 30 | 82000507 | SEAL |
| 31 | 80201209 | SCREW M6X12 |
| 32 | 80201303 | WASHER 6 |
| 33 | 80900403 | HOUSING MOTOR |
| 34 | 7731C150 | STATOR |
| 35 | 80201266 | SCREW 3,9X60 |
| 36 | 80900286 | BAFFLE |
| 37 | 80201277 | TX SCREW 5X20 |
| 38 | 77M21590 | HANDLE |
| 39 | 83000051 | RUBBER HV1305 |
| 40 | 80900000 | STOPPER |
| 41 | 80900098 | GRIP INT. |
| 42 | 83000004 | SLEEVE |
| 43 | 80600060 | POWER CABLE |
| 44 | 80201270 | SCREW 4,2X13 |
| 45 | 85000020 | CLAMP FIXED CABLE |
| 47 | 80600510 | SWITCH |
| 48 | 80500010 | CAPACITOR |
| 49 | 80201302 | WASHER 5 |
| 51 | 80600072 | CABLE |
| 52 | 80200582 | PIN 4X12 |
| 53 | 80201280 | SCREW 4,8X22 |
| 55 | 80900119 | COVER |
| 56 | 80900201 | STOPPER |
