HUfirma Pressure Washer HU 4600 DS Parts
€17.72
Tax included
HUfirma Spare Parts for Pressure Washer HU 4600 DS
We have the original Spares Hufirma for Pressure Washer HU 4600 DS - 15221, the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
HUfirma Spare Parts for Pressure Washer HU 4600 DS
We have the original Spares Hufirma for Pressure Washer HU 4600 DS - 15221, the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.In the following table, look for the model of the Pressure Washer and the respective parts of the code.
| Pressure Cleaner HU 4600 DS - 15221 | ||
Chassis Pag.1 |
||
| # | Part Num | Description |
| 1 | 4380640 | Handle |
| 2 | 4380691 | Knob |
| 3 | 50943 | Screw |
| 4 | 4383332 | Guard |
| 5 | 4383320 | Guard |
| 6 | 4383413 | Guard |
| 7 | 4380650 | Casing |
| 8 | 50943 | Screw |
| 9 | 3081390 | Screw |
| 10 | 5480500 | Screw |
| 11 | 4380680 | Base |
| 12 | 3081390 | Screw |
| 13 | 3080580 | Cable gland |
| 14 | 4580809 | Plug |
| 15 | 4580675 | Knob |
| 16 | 4720250 | Lock |
| 17 | 4380590 | Guard |
| 18 | 4380580 | Guard |
| 19 | 4380491 | Base |
| 20 | 4380540 | Accessories carrier |
| 21 | 2180330 | Rubber foot |
| 22 | 50943 | Screw |
| 23 | 4383420 | Accessories carrier |
| 24 | 4383400 | Support |
| 25 | 3081390 | Screw |
| 26 | 4580590 | Accessories carrier |
| 27 | 5480500 | Screw |
| 28 | 4720760 | Wheel |
| 29 | 4380623 | Guard |
| M | 4381470 | Screw kit |
| Hose Reel Pag.2 | ||
| 1 | 4380470 | Bracket |
| 2 | 50943 | Screw |
| 3 | 3080200 | Plate |
| 4 | 4380550 | Shim |
| 5 | 50943 | Screw |
| 6 | 4380460 | Bracket |
| 7 | 4380560 | Lever |
| 8 | 4380452 | Knob |
| 9 | 5460700 | Screw |
| Electric Pump Pag.3 | ||
| 1 | 4720680 | Electric pump assembly |
| 2 | 4380170 | Conveyor |
| 3 | 5480500 | Screw |
| 4 | 4720590 | Shim |
| 5 | 4380160 | Conveyor |
| 6 | 4720480 | Support |
| 7 | 5480500 | Screw |
| 8 | 4720500 | Spring |
| 9 | 4720610 | Switch |
| 10 | 4720470 | Pin |
| 11 | 4720750 | Cover |
| 12 | 4383370 | Extension |
| 13 | 3081440 | Capacitor |
| 14 | 4383520 | Fitting |
| 15 | 5480770 | Inductance |
| 16 | 3082360 | Cable |
| A | 3081290 | Valves + seals kit |
| B | 3081270 | Piston + seals kit |
| C | 4384420 | TSS kit |
| D | 4720810 | Brush kit for motor |
| E | 4384310 | Valve kit TSS |
| Sprayer Pag.4 | ||
| 1 | 5340240 | Pipe |
| 2 | 3440720 | Filter |
| 3 | 5340120 | Plug |
| 4 | 5340400 | Plug |
| 5 | 5340110 | Tank |
| 6 | 5340450 | Set wires |
| 7 | 2100300 | Screw |
| 8 | 5340470 | Box kit [Switch] |
| 9 | 5340440 | O-ring |
| 10 | 2000210 | Screw |
| 11 | 5340170 | Clamp |
| 12 | 5340390 | Pump assembly |
| 13 | 5340160 | Support |
| 14 | 5340180 | Insert |
| 15 | 3083300 | Fitting |
| 16 | 5340420 | Gland |
| 17 | 2100300 | Screw |
| 18 | 5000570 | Plug |
| 19 | 5340460 | Support kit |
| 20 | 5340380 | Pipe |
| 21 | 5340090 | Nozzle |
| 22 | 5340360 | Lance head |
| 23 | 5320020 | Lance |
| 24 | 5340350 | Filter |
| 25 | 5340370 | Gun |
| 26 | 5340100 | Accessories carrier |
| Accessories Pag.5 | ||
| 1 | 4381482 | Gun |
| 2 | 3083700 | O-ring |
| 3 | 4381492 | Extension (Lance) |
| 4 | 3083370 | O-ring |
| 5 | 4100800 | Lance head (Rotopower) |
| 6 | 4101550 | Lance head (Adjustable jet) |
| 7 | 3083400 | O-ring |
| 8 | 4821170 | High pressure hose |
| 9 | 3082130 | Water coupling kit |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Annovi&Reverberi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Annovi&Reverberi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
HUfirma HU 4600 DS - 15221
6 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10/15 BUSINESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N AR:
- AR S/N START WITH ( 1 or 2 ) and have 5 DIGITS
