Hitachi Parts for Orbital Sander SV12SD
search
  • Hitachi Parts for Orbital Sander SV12SD
  • Hitachi Spare Parts for Sanders

Hitachi Parts for Orbital Sander SV12SD

€19.38
Tax included

Hitachi Parts for Orbital Sander SV12SD

Hitachi-HIKOKI Tanaka Authorized Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Orbital Sander SV12SD.
ITEM CODE: 300090
Quantity
Usually Ships in: 7/10 Business Days Approx

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Hitachi Parts for Orbital Sander SV12SD

Hitachi-HIKOKI Tanaka Authorized Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Orbital Sander SV12SD.

In the following table, look for the model of the Sander and their spare part.
Hitachi SV12SD

ORBITAL SANDER SV12SD
# Part Num. Description
1 6001DD BALL BEARING 6001DDCMPS2L
2 300158 SLEEVE
3 992013 SEAL LOCK FLAT HD. SCREW M5X14
4 300172 FRAME
5 300317 RUBBER LEG
6 300161 LEVER
7 953066 DISTANCE PIECE
8 993539 MACHINE SCREW (W/WASHERS) M4X16
9 300159 FAN
10 300160 DUST FAN GUIDE
11 949216 MACHINE SCREW M4X10
12 300165 FELT (A)
13 300164 DUST GUIDE
14 300162 PAPER HOLDER
15 953320 SPRING
16 872971 RETAINING RING (E-TYPE) FOR D3 SHAFT
17A 316549 HOLDER BAR
18 300173 BOTTOM PLATE
19 300166 FELT
20 6203DD BALL BEARING 6203DDCMPS2L
21 300167 BALANCE WEIGHT
22A 300318 COVER
24 300090 SANDING PAD (PERFORATED)
25 949454 SPRING WASHER M5
26 949238 MACHINE SCREW M5X14
27 982095 TAPPING SCREW (W/WASHER) D4X20
28 300157 HANDLE COVER
29 940811 PUSHING HOLDER
30 957747 SWITCH (A) (1P SCREW TYPE) W/LOCK
30 971667Z SWITCH (2P PILLAR TYPE) W/LOCK
31 981373 TUBE (D)
32 980063 TERMINAL
33 992635 EARTH TERMINAL
34 959140 CONNECTOR 50091
35 994273 NOISE SUPPRESSOR
36 930153 SUPPORT (B)
37 300156 TOP COVER
38 300319 MACHINE SCREW (+-HD.) M5X60
39 999041 CARBON BRUSH (1 PAIR)
40 930483 BRUSH HOLDER
41 300154 HOUSING
43 300179 INTERNAL WIRE
44 305775 CHOKE COIL SET
45 300175 INTERNAL WIRE
45 300176 INTERNAL WIRE
46A 340719N STATOR 230V-240V
47 608VVM BALL BEARING 608VVC2PS2L
48 953174 HEX. HD. TAPPING SCREW D5X55
49 300155 FAN GUIDE
50 360124E ARMATURE 220V-230V
50 360124F ARMATURE 230V-240V
51 946362 BEARING LOCK
53 500234Z CORD
54 981373 TUBE (D)
55 980063 TERMINAL
56A 305812 TAPPING SCREW (W/FLANGE) D4X16 (BLACK)
57 937631 CORD CLIP
58 953327 CORD ARMOR D8.8
58 938051 CORD ARMOR D10.1
501 300177 DUST BAG
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
