Fox Spare Parts for Sliding Mitre Saw F36-255
€9.96
Tax included
Fox Spare Parts for Slide Compound Mitre Saw F36-255
Fox original spare parts, at discounted prices, we are a service center with after-sales service able to quickly solve the maintenance and repair any issues for Slide Compound Mitre Saw for Wood F36-255.
- Spare parts for FEMI SPA DISTRIBUTION - NOT Suitable for DELTA FRANCE Mitre Saws
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Fox Spare Parts for Slide Compound Mitre Saw F36-255
Fox original spare parts, at discounted prices, we are a service center with after-sales service able to quickly solve the maintenance and repair any issues for Slide Compound Mitre Saw for Wood F36-255.
- Spare parts for FEMI SPA DISTRIBUTION - NOT Suitable for DELTA FRANCE Mitre Saws
In the following table, look for the model of theSliding compound mitresaw and the respective parts of the code.
| Slide Compound Mitre Saw Fox F36-255 | ||
| # | Part Num. | Description |
| 10 | F36255-10 | ROTATING TABLE HANDLE |
| 101 | F36255-101 | BLADE PROTECTION SPRING |
| 102 | F36255-102 | PROTECTION PLATE |
| 106 | F36255-106 | PROTECTION GUARD SHROUD BLOCK |
| 107 | F36255-107 | PROTECTION GUARD |
| 108 | F36255-108 | PROTECTION GUARD FIXED COVER |
| 109 | F36255-109 | TRASPARENT PROTECTION SELF BLOCK |
| 111 | F36255-111 | SMALL SPRING |
| 112 | F36255-112 | TURNOVER AXIS |
| 119 | F36255-119 | SELF-LOCKED SPRING |
| 120 | F36255-120 | SELF LOCK |
| 121 | F36255-121 | FAN SHROUD |
| 122 | F36255-122 | ARMATURE |
| 123 | F36255-123 | BALL BEARING |
| 125 | F36255-125 | STATOR |
| 126 | F36255-126 | MOTOR HOUSING |
| 128 | F36255-128 | BRUSH HOLDER |
| 129 | F36255-129 | CARBON BRUSHE SET |
| 130 | F36255-130 | BRUSH COVER |
| 134 | F36255-134 | LIFT HANDLE |
| 136 | F36255-136 | HANDLE COVER |
| 138 | F36255-138 | SWITCH |
| 139 | F36255-139 | NETHER HANDLE |
| 140 | F36255-140 | INDUCTION |
| 144 | F36255-144 | CABLE WITH PLUG |
| 145 | F36255-145 | CAPABILITY |
| 146 | F36255-146 | SWITCH KEY |
| 147 | F36255-147 | SPRING |
| 148 | F36255-148 | SCREW |
| 15 | F36255-15 | ROTATING TABLE |
| 150 | F36255-150 | COMPLETE MOTOR |
| 151 | F36255-151 | COMPLETE VICE |
| 18 | F36255-18 | SCALE |
| 2 | F36255-2 | BASE |
| 21 | F36255-21 | CUTTING ASSISTANT |
| 25 | F36255-25 | FENCE |
| 28 | F36255-28 | KNOB |
| 3 | F36255-3 | BASE FOOT |
| 36 | F36255-36 | LINK SUPPORT PLATE |
| 37 | F36255-37 | SPECIAL SCREW |
| 38 | F36255-38 | BUSHING |
| 40 | F36255-40 | BIG SPRING |
| 41 | F36255-41 | PROTECTION GUARD PIN |
| 42 | F36255-42 | STAND |
| 43 | F36255-43 | ROUND SCREW |
| 44 | F36255-44 | DEPTH ADJUSTMENT BLOCK |
| 46 | F36255-46 | SELF-LOCKED PIN |
| 47 | F36255-47 | SELF-LOCKED SPRING |
| 49 | F36255-49 | PROTECTION GUARD SELF-LOCKED PIN |
| 50 | F36255-50 | LASER 9X20 |
| 500 | F36255-500 | LASER ASS'Y |
| 51 | F36255-51 | LASER SEAT |
| 52 | F36255-52 | FIXED SEAT |
| 56 | F36255-56 | BATTERY BOX |
| 58 | F36255-58 | BATTERY |
| 59 | F36255-59 | BATTERY BOX COVER |
| 60 | F36255-60 | SPACER RING |
| 63 | F36255-63 | ROTATING TABLE STAND |
| 65 | F36255-65 | TRACK LOCKED HANDWHEEL |
| 67 | F36255-67 | DOUBLE HEAD SCREW |
| 7 | F36255-7 | EXTENSION ROD |
| 70 | F36255-70 | STAND LOCKED HANDLE |
| 71 | F36255-71 | LINEAR BEARING |
| 72 | F36255-72 | TELESCOPIC ROD |
| 73 | F36255-73 | TRACK END COVER |
| 75 | F36255-75 | BLADE SCREW |
| 76 | F36255-76 | OUTER FLANGE |
| 78 | F36255-78 | BLADE FIXED CIRCLE |
| 79 | F36255-79 | INNER FLANGE |
| 80 | F36255-80 | OUTPUT AXIS |
| 81 | F36255-81 | FLAP |
| 84 | F36255-84 | BEARING GLAND |
| 85 | F36255-85 | 6203BEARING |
| 86 | F36255-86 | BEARING HOUSE |
| 87 | F36255-87 | BIG GEAR |
| 88 | F36255-88 | DIA 17 CIRCLIP |
| 89 | F36255-89 | HK161210 ROLLOR PIN BEARING |
| 90 | F36255-90 | DUST BAG |
| 96 | F36255-96 | LINK |
| 97 | F36255-97 | BLADE SCREW |
| 99 | F36255-99 | TRANSPARENT PROTECTION |
