Flex Spare Parts for Angle Grinder L 3206 CD
€9.71
Tax included
Flex Spare Parts for Angle Grinder L 3206 CD
FLEX Power Tools Original spare parts at attractive and competitive prices on the web, we are a service center with a repair service able to quickly solve the maintenance or repair any issues for Angle Grinder L 3206 CD - 01.07.2012.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Flex Spare Parts for Angle Grinder L 3206 CD
FLEX Power Tools Original spare parts at attractive and competitive prices on the web, we are a service center with a repair service able to quickly solve the maintenance or repair any issues for Angle Grinder L 3206 CD - 01.07.2012.In the following table, look for the model of the Angle Grinder and the respective parts of the code.
| Angle Grinder L 3206 CD - 01.07.2012 | |
| Part Num. | Description |
| 100080 | NUT M14 |
| 107700 | WASHER 6203JVS |
| 112321 | FELT PARAGRASSO |
| 114456 | SEEGER X BH 812 |
| 120081 | SHEATH CABLE |
| 120197 | SEAL GOM. L 2106/1206 |
| 129429 | RING, SICHER.- 37X1,5 DIN 472 |
| 171042 | BEARING 6203 2RS |
| 187925 | CABLE PLUG ELETT.CON 2806-2106 |
| 191604 | RING SW 17 |
| 193461 | SCREW |
| 193488 | SCREW 5X45-LG 1707 FR |
| 195693 | SCREW LK 604 4X30 |
| 195715 | SCREW LK 604 4X12 |
| 195715 | SCREW LK 604 4X12 |
| 200298 | RUBBER BEARING |
| 206245 | 40X20 SCREW |
| 240842 | 5X70 SCREW |
| 254930 | ROLLER BEARING |
| 255691 | CLAMP LXGFL0 |
| 258139 | KIT GEAR L 2106 S |
| 258739 | NUT PINION STOP X 2106 VT |
| 259148 | BEARING 6001 2RS |
| 264784 | PIGNONE X L 3206 |
| 264970 | STATOR X L 3206 |
| 265004 | HEAD X L3206 |
| 265055 | GRIP X L3206 |
| 265101 | COVER COPRISPAZ.LD 3206 C |
| 265128 | STARTING SLOW DIODE L 3206 |
| 265136 | SHAFT HEAD COMP.L 3206 |
| 265179 | SAFETY CAP WITH LEVER D |
| 265918 | SWITCH |
| 267554 | FAN X L 3206 |
| 270334 | BUTTON X L 3206 |
| 270679 | SCHUTZH.M.VORD.230 O.VERSCHR. |
| 270741 | PARAVENTOLA X L 3206 |
| 271195 | CLAMP |
| 271209 | LOCKING BRACKET |
| 271217 | LOCKING PLATE |
| 271381 | WASHER X L3206 |
| 271403 | PIN X L3206 |
| 271411 | SPRING X L 3206 |
| 271837 | LEVER DIRECTION IMP. |
| 271845 | SPRING X L 3206 |
| 272493 | SPACERS MM.0,2 |
| 277746 | RING X L 3206 |
| 279554 | FERMACAVOL 3206 |
| 279560 | SCREW M6X10 DIN7991 |
| 279684 | BOTTOM X L3206 |
| 281786 | WASHER X L 3206 |
| 283797 | NUT X L3226 |
| 284122 | SCREW, M 5X 12 DIN 912 |
| 286206 | NUT X L3206 |
| 297356 | BEARING 6301-2RS-C3 |
| 314730 | L3206 RING |
| 314765 | SHOCK L3206 |
| 322229 | ARMATURE X L 3206 |
| 322733 | MOTOR BODY BEDR. U. MONT. |
| 325279 | CARBON BRUSHE ASSY L 3206 C (EX279439) |
| 333891 | SCREW, KT 5X18 T20 |
| 383538 | ELEKTRONIK M.WIEDERANLAUFSCH. |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Flex websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Flex brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Flex L 3206 CD
6 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
