Spare Parts for Pump Unit FIAC GM 260
€504.10
Tax included
Spare Parts for Pump Unit FIAC GM 260
We have the original Spares FIAC for Pump Unit FIAC GM 260 validity date - from 14/04/2003 Single Phase cod.2022500000 - Three-Phase cod. 2022510000, the diagram, parts list and tool repair that help you need to get your tools running like new again.Fix Your FIAC GM 260. All Spares are original and can be supplied at Low and discounted prices.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Spare Parts for Pump Unit FIAC GM 260
We have the original Spares FIAC for Pump Unit FIAC GM 260 validity date - from 14/04/2003 Single Phase cod.2022500000 - Three-Phase cod. 2022510000, the diagram, parts list and tool repair that help you need to get your tools running like new again.
In the following table , look for the model of the pumping unit and the respective parts of the code.
| GM 260 validity date - from 14/04/2003 | ||
| # | Part Num. | Description |
| 1 | 7012080000 | Screw Ø4,2X12,7 UNI-6954 |
| 2 | 7248030000 | REAR VENT GMV BLACK |
| 3 | 7011090000 | Screw M8x20 UNI-5739 |
| 4 | 7031010000 | Washer Ø8 UNI-3703 |
| 5 | 7012020000 | Screw Ø3,9X12,7 DIN-7981 |
| 6 | 7382340000 | Terminal cover |
| 7 | 7200020000 | Fan raff. |
| 8 | 7248020000 | PROTECTION FRONT VENT.GMV BLACK |
| 9 | 5110020008 | CAP POSTER.GM 260 / GMS 150-180 |
| 10 | 7038020000 | Washer Ø8X30X3 UNI-6593 |
| 11 | 7085020000 | Fitting 1/2 "-3/8" MF |
| 12 | 7060030000 | Bearing 6204 20-47-14 2RS1- |
| 13 | 4011720000 | CARC.MOTORE GM 260 V.230 / 50HZ |
| 14 | 7660050000 | Rotor |
| 15 | 7310420000 | Capacitor MF.32 V450 |
| 16 | 7060060000 | Bearing 6205 |
| 17 | 5070100008 | Sump |
| 18 | 5040201008 | Tree in Elbow |
| 19 | 5050150008 | Piston rod |
| 20 | 7015020000 | Stud M.8X35X14X16 |
| 21 | 7012060000 | Screw M4X12 UNI-8112 |
| 22 | 7015090000 | Guy M6X115 |
| 23 | 7040040000 | And Seeger 20 |
| 24 | 7078120000 | Gasket |
| 25 | 5080020008 | COVER CARTER GM 260 |
| 26 | 7090090000 | Cap M1 / 4 "Brass |
| 27 | 7090090000 | Cap M1 / 4 "Brass |
| 28 | 7012010000 | Screw Ø3,9X19 UNI-6954 |
| 29 | 7181020000 | Dipstick |
| 30 | 7041030000 | Seeger Ø13 |
| 31 | 7050030000 | Pin Ø 13 |
| 32 | 7220050000 | Piston |
| 33 | 4080030000 | Kit segments |
| 35 | 7071020000 | Oil seal 2452/10 |
| 36 | 7210090000 | FILTER M1-1/2" |
| 37 | 7501060000 | Cable locks |
| 38 | 7501050000 | Cable locks |
| 39 | 7084030000 | A fitting L 1/2 TUBE D14 |
| 40 | 7011340000 | Screw M6x55 UNI-5737 |
| 41 | 7196010000 | Start valve M3 / 8 "1.5 bar |
| 42 | 7570020000 | Head |
| 44 | 7458240000 | Valve plate |
| 45 | 4081010000 | FLAP VALVE KIT 10 PCS 110-200 |
| 46 | 7458240000 | Valve plate |
| 48 | 7575000000 | Cylinder |
| 49 | 7020070000 | Nut M8 UNI-5587 |
| 100 | 4082720000 | Valve plate kit |
| 101 | 4191060000 | KIT ROD-PISTON D.55 |
| 102 | 4280060000 | GR.CARTER + TREE + ROTOR GM 260 MONO |
| 103 | 4082070000 | Kits |
| 006A | 7382070000 | Terminal cover |
| 013A | 4011720000 | CARC.MOTORE GM 260 V.230 / 50HZ |
| 013B | 4010450000 | CAR.STAT GM260 125X65X80 V.400 / 50HZ |
| 014A | 7660060000 | Rotor |
| 018A | 5040211008 | Tree-phase |
| 102A | 4280110000 | GR CARTER + CRANKSHAFT + ROTOR GM 260 FRR |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Fiac websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Fiac brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
