Femi Spare Parts for Miter Saw for Wood TR075 - 8426128
€4.21
Tax included
Femi Spare Parts for Miter Saw for Wood TR075 - 8426128
Femi Genuine spare parts or replacement parts for to repair Miter Saw for Wood TR075 - 8426128.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Femi Spare Parts for Miter Saw for Wood TR075 - 8426128
Femi Genuine spare parts or replacement parts for to repair Miter Saw for Wood TR075 - 8426128.
In the following table, look for the model of Miter Saw and the respective parts of the code.
| Miter Saw TR075 - 8426128 | ||
| # | Part Num. | Description |
| 4 | F36075-004 | RUBBER FEET |
| 6 | F36075-006 | LOCATED SPRING |
| 7 | F36075-007 | STEEL BALL D.8 |
| 12 | F36075-012 | TIGHTED BOLT |
| 14 | F36075-014 | BASE |
| 16 | F36075-016 | EXTENTIONAL FEET |
| 19 | F36075-019 | ROUND BASE |
| 21 | F36075-021 | TABLE COVER |
| 22 | F36075-022 | RIP FENCE |
| 24 | F36075-024 | BLADE PROTECTOR |
| 25 | F36075-025 | SHORT AXES |
| 26 | F36075-026 | SUPPORTER |
| 28 | F36075-028 | TIGHTED SCREW |
| 30 | F36075-030 | BAR HOLDER |
| 31 | F36075-031 | INCLINED CUTTING POINTER |
| 32 | F36075-032 | TIGHTED SPANNER |
| 33 | F36075-033 | SPRING |
| 39 | F36075-039 | FRAME PROTECTER |
| 40 | F36075-040 | DUST TIE-IN |
| 41 | F36075-041 | BOLT |
| 41 | F36075-042 | WASHER |
| 43 | F36075-043 | OUTSIDE FLANGE |
| 45 | F36075-045 | INSIDE FLANGE |
| 47 | F36075-047 | TRANSPARENT GUARD BAFFLE |
| 49 | F36075-049 | FRONT TRANSPARENT GUARD |
| 50 | F36075-050 | UPPER CONNECT BAR |
| 57 | F36075-057 | LEVER CONNECTOR |
| 58 | F36075-058 | LOCK AND RELEASE RIVET |
| 60 | F36075-060 | BEARING |
| 62 | F36075-062 | BEARING HOUSE |
| 63 | F36075-063 | GEAR |
| 64 | F36075-064 | PRINCIPAL AXIS |
| 67 | F36075-067 | NEEDLE BEARING HK0910 |
| 68 | F36075-068 | PUSHER |
| 80 | F36075-080 | KNIFE SUPPORT |
| 81 | F36075-081 | BLADE FELLOW |
| 84 | F36075-084 | FRAME PRESS BOARD |
| 86 | F36075-086 | FRAME |
| 87 | F36075-087 | BEARING 6200 |
| 88 | F36075-088 | ARMATURE |
| 94 | F36075-094 | STATOR |
| 96 | F36075-096 | HOUSING |
| 97 | F36075-097 | BRUSH HOLDER |
| 98 | F36075-098 | COPPER SET |
| 99 | F36075-099 | CARBON BRUSHE SET |
| 100 | F36075-100 | HOUSING COVER |
| 104 | F36075-104 | UPPER HANDLE |
| 105 | F36075-105 | LOWER HANDLE |
| 107 | F36075-107 | SWITCH |
| 108 | F36075-108 | CAPACITANCE |
| 110 | F36075-110 | LOCKING PIN BUTTON |
| 111 | F36075-111 | JUNCTION BOX |
| 116 | F36075-116 | SQUARE SHAPED INDUCTOR |
| 117 | F36075-117 | JUNCTION BOX COVER |
| 122 | F36075-122 | MAIN SWITCH |
| 129 | F36075-129 | PROTRACTOR GUIDE |
| 130 | F36075-130 | TOP TABLE |
| 131 | F36075-131 | TABLE LINING PLATE |
| 132 | F36075-132 | TABLE TIGHTED KNOB |
| 133 | F36075-133 | TABLE TIGHTED SCREW |
| 134 | F36075-134 | SCALE LABEL |
| 135 | F36075-135 | RIGHT TABLE COVER |
| 147 | F36075-147 | PROTECTING PLUGBOARD |
| 148 | F36075-148 | COVER |
| 149 | F36075-149 | COMPLETE PROTECTION |
| 150 | F36075-150 | COMPLETE LEVER |
| 151 | F36075-151 | COMPLETE GONIOMETER |
| 152 | F36075-152 | COMPLETE MOTOR |
| 153 | F36075-153 | COMPLETE VICE |
| 156 | F36075-156 | THERMIC PROTECTION |
| 158 | F36075-158 | COMPLETE PROTECTION+LEVERS |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Femi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Femi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Femi TR075 - 8426128
6 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK ITEM CODE OR S/N FEMI:
- FEMI ITEM CODE START WITH (8....) AND HAVE 7 DIGITS
