Dolmar Bruschcutter MS352.4R Parts
€232.22
Tax included
Dolmar Spare Parts for Bruschcutter MS352.4R
DOLMAR repair center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Brush Cutter Dolmar MS352.4R.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Dolmar Spare Parts for Bruschcutter MS352.4R
Fix Your Brushcutter Dolmar MS352.4R. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the Brush Cutter and the respective parts of the code.
| Bruschcutter DOLMAR MS352.4R | ||
| Pag.1 | ||
| # | Part Num | Description |
| 1 | 177930010N | GEARBOX CPL EBH341R |
| 2 | XNR0000098 | TORX SCREW M5X20 RBK350 |
| 3 | 065051000N | TORX SCREW M5X10 RBK350 |
| 4 | 065060800N | TORX SCREW M6X8 RBK350 |
| 5 | 108230120N | GEARBOX CPL EBH341R |
| 6 | 035600000C | BALL BEARING EBH341R |
| 7 | 140077200N | BEVEL GEAR EBH341R |
| 8 | 175030300N | SHAFT EBH341R |
| 9 | 035600103N | BALL BEARING 6001LL |
| 10 | 045002800N | RETAINING RING R-28 RBK350 |
| 11 | XNR0000158 | INTERNAL FLANGE RBK350 |
| 12 | XNR0000473 | COVER B EBH341R |
| 13 | XNR0000348 | FLANGE EBH341R |
| 14 | 174932210N | NUT X EBH341R |
| 15 | 045002600N | RETAINING RING R-26 RBK350 |
| 16 | 045001002N | RETAINING RING S-10 RBK350 |
| 17 | 035600001C | BEARING 6000Z X EBH341R |
| 18 | XNR0000350 | COVER FOR EBH341R |
| 19 | 6118002000 | GUARD FOR BRUSHCUTTER |
| 20 | 6118002010 | GUARD FOR RBK420G |
| 21 | 6118002020 | PLATE FOR RBK420G |
| 22 | 6118002030 | SCREW M5 X 20 EBH341R |
| 23 | 164619300N | PIN FOR EBH341R |
| 24 | 164619600N | TORX SPRING FOR EBH341R |
| 25 | 065061800N | TORX SCREW M6X18 RBK350 |
| 26 | XNR0000065 | RETAINING RING E-5 RBK350 |
| 27 | 103310100N | CLUTCH CASING EBH341R |
| 28 | XNR0000070 | RETAINING RING S-15 X RBK350 |
| 29 | 035620202C | BEARING EBH341R |
| 30 | XNR0000075 | RETAINING RING R-35 RBK350 |
| 31 | XNR0000183 | CLUTCH DRUM |
| 32 | 173248500N | HANDLE SHOCK ABSORBER X EBH341R |
| 33 | 065053000N | SCREW X EBH341R |
| 34 | 031050001N | WASHER 5 X EBH341R |
| 35 | 173148200N | GRIP X EBH341R |
| 36 | 174048410N | LOWER HANDLE EBH341R |
| 37 | XNR0000187 | FLEXIBLE SHAFT |
| 38 | 182420300N | PIPE COVER X RBK350 |
| 39 | 102118400N | PIPE COVER X EBH341R |
| 40 | XNR0000326 | FLEXIBLE SHAFT BHK3500 |
| 41 | 102121200N | JOINT X EBH341R |
| 42 | 102121100N | SHAFT X EBH341R |
| 43 | 6119522200 | LABEL MS352.4R |
| 44 | 102120100N | COMPLETE ROD X EBH341R |
| 45 | XNR0000098 | TORX SCREW M5X20 RBK350 |
| 46 | 065050810N | SCREW M5 X 8 X EBH341R |
| 47 | 102119100N | JOINT COVER X EBH341R |
| 48 | 065053020N | SCREW M5X30 EBH341R |
| 49 | XNR0000474 | BRACES |
| 50 | 085051209N | SCREW M5 X 12 X EBH341R |
| 51 | 103415900N | FRAME X BRACE X EBH341R |
| 52 | 014082000N | SCREW M8X20 EBH341R |
| 53 | 035620102C | BEARING EBH341R |
| 54 | 164615811N | BEARING BOX X EBH341R |
| 55 | 106746100N | ENGINE MOUNT X EBH341R |
| 56 | 065052500N | SCREW M 5 X 25 X EH490V |
| 57 | 106746600N | REAR MOUNT X EBH341R |
| 58 | 106746500N | FRONT MOUNT EBH341R |
| 59 | XNR0000234 | ANTI-VIBRATION |
| 60 | 030061400N | M6 NUT FOR RBK350 |
| 61 | XNR0000131 | BCX2510 CONTROL LEVER |
| 62 | 178724000N | EBH341R COLLAR |
| Pag.2 | ||
| 63 | 0119059531 | M5 X 16 SCREW FOR MS351-4U |
| 64 | 5935500200 | FAN CASING FOR MS351-4U |
| 65 | 266571-9 | M8X23 SCREW FOR EBH341U |
| 66 | 0200089800 | CLUTCH WASHER FOR MS351-4U |
| 67 | 125757-3 | CLUTCH COMPLETE FOR EM3400L |
| 68 | 5318003020 | SPRING FOR MS351-4U |
| 69 | 0130069940 | M6X16 SCREW FOR BHX2500 |
| 70 | 5937001021 | FLYWHEEL EBH341R |
| 71 | 168816-0 | IGNITION COIL EBH341U |
| 72 | 0043704200 | M4X20 SCREW FOR BHX2500 |
| 73 | 324891-8 | SPRING SPARK PLUG CAP EBH341 |
| 74 | 424105-6 | SPRING SPARK PLUG CAP EBH252L |
| 75 | 5927003000 | CABLE COMPLETE MS251.4 |
| 76 | 5257018001 | STOP CABLE RBC201 |
| 77 | 5257500300 | RUBBER X HT2256D-HT2276E |
| 78 | 0566059980 | BRACKET X RBC525 |
| 79 | 5929501300 | LABEL X MS351-4U |
| 80 | 5935500500 | SPINNER COVER X MS351-4U |
| 81 | 0140059921 | SCREW M5 X 8 X MP352.4Z |
| 82 | 0140059370 | SCREW M5 X 12 X MP352.4Z |
| 83 | 5935500901 | ENGINE COVER X MS351-4U |
| 84 | 0119059520 | SCREW M5 X 40 RBC201 |
| 85 | 0140059962 | SCREW M 5 X 6 MS251.4 |
| 86 | 5923503400 | MUFFLER COVER MS251.4 |
| 87 | 168469-5 | MUFFLER EBH341U |
| 88 | 5923501601 | MUFFLER GUARD MS251.4 |
| 89 | 5923008011 | SPARK GUARD FOR BHX2500 |
| 90 | 0043605160 | SCREW M 5 X 16 X MS251.4 |
| 91 | 5931004000 | HEAD COVER X MS351-4U |
| 92 | 162307-3 | BROWN COVER GASKET |
| 93 | 0650109950-10 | CMR6A SPARK PLUG X MS251.A (10PCS) |
| 94 | 123991-9 | CYLINDER GROUP |
| 95 | 162274-2 | SIDE COVER GASKET EBH341 |
| 96 | 5921500502 | SIDE COVER FOR MS251.4 |
| 97 | 0043605140 | SCREW M5X14 FOR RBC225-255 |
| 98 | 5926500600 | OIL CAP FOR MS251.4 |
| 99 | 0213169990 | OIL COVER CAP GASKET MS351-4U |
| 100 | 0561059970 | CLAMP FOR PIPE FOR BHX2500 |
| 101 | 5926500200 | OIL PIPE FOR MS251.4 |
| 102 | 5926500300 | FITTING FOR MS251.4 |
| 103 | 0043605180 | SCREW COMP. FOR RBC230/RBC520 |
| 104 | 374650000 | OIL PAN BCX3410 |
| 105 | 5936500100 | O. PAN GASKET MS351-4U |
| 106 | 0119059470 | SCREW M 5 X 16 FOR MS351-4U |
| 107 | 266573-5 | SCREW M5X33 EBH341U |
| 108 | 0119049960 | SCREW M 4 X 10 FOR MS351-4U |
| 109 | 5921501100 | RETAINING PLATE FOR MS251.4 |
| 110 | 5921501000 | PLATE FOR MS251.4 |
| 111 | 125554-7 | BALANCE GEAR EBH341U |
| 112 | 5933500300 | SPRING COVER VAL. X MS351-4U |
| 113 | 5933500200 | VALVE SPRING X MS351-4U |
| 114 | 256200-2 | PIN 5 FOR 2704 |
| 115 | 5933500000 | ROD X MS351-4U |
| 116 | 424200-2 | SPACER EBH341U |
| 117 | 5923500600 | CAM LIFTING SHAFT X MS251.4 |
| 118 | 313169-4 | CAM ROCKER ARM EBH341U |
| 119 | 5933500400 | EXHAUST VALVE X MS351-4U |
| 120 | 5933500500 | INTAKE VALVE X MS351-4U |
| 121 | 125552-1 | CAM GEAR EBH341U |
| 122 | 5923500501 | CAM SHAFT MS251.4 |
| 123 | 195141-6 | PISTON RINGS EBH341U |
| 124 | 233983-1 | PISTON PIN RING EBH341 |
| 125 | 318613-6 | PISTON EBH341U |
| 126 | 5932500900 | PISTON PIN X EM4340L |
| 127 | 0323039990 | KEY X RBC350-RBC420 |
| 128 | 213537-0 | SEAL 12 EBH341U |
| 129 | 5932501000 | RUBBER SHAFT WASHER MS351-4U |
| 130 | 125756-5 | ECCENTRIC SHAFT EBH341U |
| 131 | 213769-9 | SEAL 10 |
| 132 | 125472-9 | TANK CAP COMPLETE |
| 133 | 5926016000 | TANK CAP MP352.4Z |
| 134 | 140436-2 | DISK EBH341U |
| 135 | 6249501501 | COLLAR PLATE MS251.4 |
| 136 | 424102-2 | SHOCK ABSORBER EBH341U |
| 137 | 162309-9 | FUEL PIPE EBH341U |
| 138 | 424103-0 | SHOCK ABSORBER EBH341U |
| 139 | 0561059990 | FILTER LOCKING STRAP TXRBC230-310/520 |
| 140 | 163447-0 | FUEL FILTER FOR DCS230T |
| 141 | 5936500200 | FUEL TANK MS351-4U |
| 142 | 5196500302 | SHOCK ABSORBER MP352.4Z |
| 143 | 195142-4 | STARTER COMPLETE EBH341U |
| 144 | 5315023000 | STARTER PULLEY X MS351-4U |
| 145 | 5425003010 | SCREW SET X RBC415-225-255 |
| 146 | 451923-9 | STARTER SPOOL EBH341U |
| 147 | 232257-7 | SPIRAL SPRING EBH341U |
| 148 | 5315001030 | LOCK X RBC415 |
| 149 | 5215002110 | STARTER X RBC 230-225-255 |
| 150 | 5315022040 | STARTER ROPE X MS351-4U |
| 151 | 5935502400 | GASKET EBH341R |
| 152 | 911218-7 | CYLINDER HEAD SCREW M5X14 |
| 153 | 6119522000 | 00 |
| 154 | 267832-0 | WAVED WASHER 10 EBH341U |
| Pag.3 | ||
| 154 | 413120-5 | INSULATING GASKET EBH341U |
| 155 | 451874-6 | INSULATOR EBH341U |
| 156 | 0021705000 | NUT M5 X RBC415 |
| 157 | 0022706000 | NUT M6 X PB500R |
| 158 | 0022706000 | NUT M6 X PB500R |
| 159 | 0149069961 | REGULATOR X EBH341R |
| 160 | 5933500600 | INSULATING PLATE X MS351-4U |
| 161 | 0140059370 | SCREW M5 X 12 X MP352.4Z |
| 162 | 5926501300 | CLAMP MP352.4Z |
| 163 | 0043605180 | SCREW COMP.X RBC230/RBC520 |
| 164 | 413138-6 | CARBURETOR GASKET EBH341 |
| 165 | 0561080010 | PIPE STOP X RBC 260/RBC520 |
| 166 | 5931500900 | BREATHER PIPE X MS351-4U |
| 167 | 422042-8 | PIPE EBH341U |
| 168 | 265188-5 | SCREW M5X68 EBH341U |
| 169 | 345919-9 | FIXING PLATE EBH341U |
| 170 | 423376-2 | GASKET EBH341U |
| 171 | 450560-6 | CHOKE LEVER PLATE EBH341U |
| 172 | 443140-5 | PRE-FILTER EBH341U |
| 173 | 443141-3 | FILTER EBH341U |
| 174 | 911218-7 | CYLINDER HEAD SCREW M5X14 |
| 175 | 450561-4 | AIR FILTER COVER EBH341U |
| 176 | 125468-0 | FILTER PLATE EBH341U |
| 177 | 451925-5 | CHOKE LEVER EBH341U |
| 178 | 213540-1 | RING 15 EBH341U |
| 179 | 424316-3 | CHECK VALVE EBH341U |
| 180 | 0240139970 | RING MS251.4 |
| 181 | 451924-7 | CHECK VALVE PLATE |
| 182 | 424315-5 | CHECK VALVE EBH341U |
| 183 | 168577-2 | SEPARATOR GASKET EBH341U |
| 184 | 5933501600 | SEPARATOR FOR MS351-4U |
| 185 | 168561-7 | CARBURETOR EBH341U |
| 186 | 5236018040 | ACC. CABLE XRBC230-260-310-225- |
| 187 | 5426005030 | WASHER X RBC350-RBC420 |
| 188 | 266581-6 | SCREW M3X8 EBH341U |
| 189 | 5316005120 | RING X RBC 260/230/310/225/2 |
| 190 | 5246001010 | GASKET X RBC 260/230/310/ |
| 191 | 5936002010 | NOZZLE X MS351-4U |
| 192 | 442155-9 | PUMP GASKET EBH341U |
| 193 | WJ00009599 | PUMP DIAPHRAGM X DCS230T |
| 194 | 5926002020 | PUMP SPRING X MS251.4 |
| 195 | 5926002140 | PUMP BODY COMPL. FOR EM4251 |
| 196 | 5016004010 | CONNECTOR FOR RBC 260/230/310/225 |
| 197 | 442154-1 | DIAPHRAGM SEAL EBH341U |
| 198 | 168574-8 | DIAPHRAGM CPL EBH341U |
| 199 | 5236046140 | BODY FOR MS251.4 |
| 200 | 424314-7 | PRIMING PUMP EBH341 |
| 201 | 5236046050 | PUMP COVER FOR RBC350-RBC42 |
| 202 | 266582-4 | SCREW 3X24 EBH341U |
| 203 | 325915-3 | SUCTION PIPE EBH341U |
| 204 | 0062610101 | RING FOR BHX2500 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Dolmar websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Dolmar brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
