DEWALT D25500K Type 1 Rotary Hammer Spare Parts
€27.57
Tax included
DEWALT D25500K Type 1 Rotary Hammer Spare Parts
DEWALT, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for DEWALT D25500K Type 1 Model: D25500K-QS Rotary Hammer.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
DEWALT D25500K Type 1 Rotary Hammer Spare Parts
DEWALT, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for DEWALT D25500K Type 1 Model: D25500K-QS Rotary Hammer.
In the following table, look for the model of the hammer and the respective parts of the code.
| DeWalt D25500K Rotary Hammer 40 MM SDS MAX - Type 1 Spare Parts | ||
| Model D25500K-QS | ||
| # | Part Num | Description |
| 103 | 581070-00 | SWITCH |
| 106 | 582319-00 | CORDSET D25980 QS |
| 112 | 323091-01 | CORD PROTECTOR, 8.9 |
| 113 | 821070 | CLAMP, CORD |
| 114 | 330065-08 | SCREW, ART.4X18 |
| 118 | 577712-00 | HANDLE COVER |
| 124 | 330065-11 | VITE,ART.4X65 |
| 126 | 577745-00 | BEARING 6000 T1XDDW |
| 127 | 325279-00 | SLEEVE MM 26 |
| 129 | 577736-00 | FAN - Discontinued |
| 130 | 324119-02 | SCREW, M5X12 |
| 131 | 326579-00 | SHUTTER |
| 133 | 326667-00 | BRUSH SPRING |
| 134 | 326933-01 | HOLDER |
| 136 | 324007-11 | SCREW, TORX, SELF. 5X18 |
| 137 | 324007-11 | SCREW, TORX,SELF. 5X18 |
| 150 | 578487-02 | GEARCASE SA |
| 151 | 577745-01 | BEARING,BALL |
| 153 | 578486-01 | GEARCASE COVER SA |
| 165 | 327141-05 | SEAL |
| 167 | 918825-02 | SCREW, CIL.M6X40/12.9 |
| 169 | 582431-00 | CRANKSHAFT |
| 170 | 323711-26 | O-RING |
| 171 | 325002-00 | CON ROD |
| 172 | N041843 | PISTON 8.60 NEW N041843 |
| 173 | 330041-22 | PISTON PIN, 8X24 |
| 174 | 325905-00 | RETAINER D=25.6 |
| 175 | 576232-01 | O-RING |
| 177 | 577744-00 | O-RING |
| 181 | 496440-00 | REPAIR KIT |
| 183 | 323763-03 | CIRCLIP 58X61 |
| 185 | 325880-02 | SHAFT,CIL. 4,75X82,5 |
| 187 | 323395-08 | SPRING 1.25/5.2 |
| 189 | 326093-00 | SPACER |
| 190 | 577731-00 | LINK |
| 191 | 577718-00 | ECCENTRIC SA |
| 192 | 323711-07 | O-RING, O 11.5X2.4 |
| 200 | N021271 | HANDLE SA |
| 207 | 487229-00 | FILTER |
| 208 | 491348-01 | CAP + GASKET |
| 251 | 326555-00 | COLLAR, SDS |
| 252 | 326552-01 | BUSH |
| 253 | N079374 | PIN |
| 254 | N021108 | CLAMP |
| 255 | 326553-00 | LOCKING RING, SW |
| 257 | 326573-00 | SCREW WING M6 |
| 258 | 326556-00 | NUT M6 |
| 259 | 330021-01 | NUT, 6KT M6ISO7040 |
| 260 | 326205-00 | DEPTH ROD, METALLO |
| 261 | 323753-11 | WASHER 41X48 |
| 263 | 323753-14 | WASHER 44.4X50 |
| 264 | 323395-07 | SPRING 2.2/44.2 |
| 265 | 582432-01 | BEAT PIECE |
| 266 | N244259 | SEAL 5.40 old 577484-00 |
| 267 | 582381-00 | WASHER |
| 268 | 577744-02 | O-RING |
| 269 | 323753-16 | WASHER,18.5X35X1.6 , 5098-99 |
| 270 | N210233 | O-RING |
| 271 | 326044-01 | CAP |
| 273 | 325878-00 | ROLLER ,8X20 |
| 274 | 329816-00 | LIP SEAL |
| 275 | 326575-02 | COLLAR, SDS |
| 276 | 479247-00 | SLEEVE SA |
| 279 | 323395-06 | SPRING 2.2/47.8 |
| 280 | 325929-00 | HALF WASHER |
| 281 | 487118-00 | SPRING |
| 282 | 325930-00 | GUIDA,PIASTRA |
| 282 | N313860 | GUIDE |
| 283 | 327141-00 | SEAL |
| 284 | 578489-00 | HOUSING SA |
| 285 | 577727-01 | GASKET |
| 288 | 327208-00 | GUIDE |
| 290 | 578493-00 | END CAP |
| 317 | 577746-00 | RING |
| 318 | 577708-00 | COVER-TOP |
| 319 | 577709-00 | HOUSING LOWER |
| 320 | 323924-08 | SCREW, PLASTIC 5X12 |
| 322 | 326619-00 | SCREW M4X8 |
| 400 | 493136-00 | COVER SA |
| 801 | 328771-07 | BIT GREASE 50G |
| 830 | 487395-01 | CARTELLO |
| 837 | 559633-99 | S.T.MANDREL |
| 839 | 559656-99 | S.T.SUPPORT JIG |
| 840 | 559597-99 | S.T.ASSEMBLY JIG |
| 842 | 559644-99 | S.T.LIP SEAL REMOVER |
| 843 | 559645-99 | S.T.SEAL FITTING TOOL |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s DEWALT websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to DEWALT brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
