Compa-OMS Spare Parts for Combined machines Baby-KOMPACTA 200/L6
€37.98
Tax included
Compa-OMS Spare Parts for Combined Machine Baby-KOMPACTA 200/L6
COMPA-OMS authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Combined Machine Baby-KOMPACTA 200/L6.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Compa-OMS Spare Parts for Combined Machine Baby-KOMPACTA 200/L6
COMPA-OMS authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Combined Machine Baby-KOMPACTA 200/L6.In the following table, look for the model of the Portable Saws and their spare part.
| Baby-KOMPACTA K200/L6 Pag.1 | ||
| # | Part Num. | Description |
| 1 | K200L6.00.001 | Supplemental accident prevention plan |
| 2 | K200L6.00.002 | Accessory box full K200L6 |
| 1 | K200L6.01.001 | Guide right x Baby Kompacta 200 L6 |
| 4 | K200L6.01.004 | Bushing 4 x Baby - Kompacta 200 L6 |
| 5 | K200L6.01.005 | Support surface plate graph |
| 7 | K200L6.01.007 | Cursor x Baby-Komp. 200L6 |
| 8 | K200L6.01.008 | Square nut x Baby - Kompacta 200 L6 |
| 10 | K200L6.01.010 | Plan Front x Baby - Kompacta 200 L6 |
| 11 | K200L6.01.011 | Nut 2 x Baby Komp.200 L6 |
| 12 | K200L6.01.012 | Guide Fence x Baby Komp.200 L6 |
| 13 | K200L6.01.013 | Locking plate protection Baby Kompacta 200 L6 |
| 14 | K200L6.01.014 | Locking plate protection Baby Kompacta 200 L6 |
| 15 | K200L6.01.015 | Knives Cover Plate x Baby Kompacta 200 L6 |
| 16 | K200L6.01.016 | knives Cover Plate Hook K200L6 |
| 18 | K200L6.01.018 | left guide |
| 20 | K200L6.01.020 | Framework for dragging anchor rollers |
| 23 | K200L6.01.023 | Drill Tip cover |
| 24 | K200L6.01.024 | Drill Tips Holder |
| 25 | K200L6.01.025 | Covers tree |
| 26 | K200L6.01.026 | Drill Tips Bushing Kit d.mm.6 x / 8/10/12 |
| 31 | K200L6.01.031 | Carter hedge cutter |
| 40 | K200L6.01.040 | Head door knives d.80 hole d.20 |
| 46 | K200L6.01.046 | Protection planer knives |
| 47 | K200L6.01.047 | Supporting block bracket |
| 48 | K200L6.01.048 | Security Support knives top |
| 49 | K200L6.01.049 | Security Support knives lower |
| 50 | K200L6.01.050 | plate |
| 51 | K200L6.01.051 | Base protection knives |
| 52 | K200L6.01.052 | Arbor screw |
| 54 | K200L6.01.054 | back plane |
| 55 | K200L6.01.055 | No comb. 2 |
| 59 | K200L6.01.059 | pin |
| 68 | K200L6.01.068 | Special nut locking adjustable floor K200L6 |
| 72 | K200L6.01.072 | Sprocket n. 2 |
| 81 | K200L6.01.081 | Lever x Baby Kompacta 200L6 |
| 82 | K200L6.01.082 | Handle x Baby Kompacta 200L6 |
| 85 | K200L6.01.085 | Stand Stopper protection |
| 86 | K200L6.01.086 | Chain transmission x Baby Kompacta 200 L6 |
| 100 | K200L6.01.100 | Group line planer |
| 101 | K200L6.01.101 | Cappa milling machine |
| Pag.2 | ||
| 23 | K200L6.02.023 | handle |
| 26 | K200L6.02.026 | gear |
| 32 | K200L6.02.032 | threaded bushing |
| 33 | K200L6.02.033 | Tensioning lever |
| 34 | K200L6.02.034 | bearing |
| 35 | K200L6.02.035 | threaded bushing |
| 36 | K200L6.02.036 | Washer x Baby K-200 L6 |
| 37 | K200L6.02.037 | Bushing x Baby Kompacta 200 L 6 |
| 38 | K200L6.02.038 | gear |
| 39 | K200L6.02.039 | spring |
| 75 | K200L6.02.075 | Flyer lifting floor thickness |
| 81 | K200L6.02.081 | Belt mot.riduttore A900 K200L6 |
| 82 | K200L6.02.082 | Belt mot.albero planer A.800 K200L6 |
| 83 | K200L6.02.083 | Complete engine K200L6 |
| A7 | K200L6.02.0A7 | spring |
| 100 | K200L6.02.100 | chain tensioner |
| Pag.3 | ||
| 1 | K200L6.03.001 | flat washer |
| 2 | K200L6.03.002 | pulley |
| 3 | K200L6.03.003 | bushing |
| 4 | K200L6.03.004 | spacer |
| 5 | K200L6.03.005 | Baby Gear x-Kompacta 200 L6 |
| 6 | K200L6.03.006 | Bushing x Baby Kompacta 200 L6 |
| 7 | K200L6.03.007 | Holder bearing x Baby Kompacta 200 L6 |
| 8 | K200L6.03.008 | bushing |
| 9 | K200L6.03.009 | bushing |
| 10 | K200L6.03.010 | post |
| 11 | K200L6.03.011 | gear |
| 12 | K200L6.03.012 | toothed shaft |
| 13 | K200L6.03.013 | Spring Baby Kompacta x 200 L6 |
| 14 | K200L6.03.014 | Control lever |
| 15 | K200L6.03.015 | tree |
| 99 | K200L6.03.099 | Reduction unit complete 200 L6 |
| B1 | K200L6.03.0B1 | Flat washer 40 n. 4 |
| B2 | K200L6.03.0B2 | Bearing 6203 2RS |
| B3 | K200L6.03.0B3 | Flat washer 18 |
| B4 | K200L6.03.0B4 | Black knob M8 x 25 |
| 100 | K200L6.03.100 | Mortiser complete K200L6 |
| Pag.4 | ||
| 14 | K200L6.04.014 | threaded pin |
| 26 | K200L6.04.026 | Cursor x Baby Kompacta 200L6 |
| 41 | K200L6.04.041 | Cursor x Baby Kompacta 200L6 |
| 44 | K200L6.04.044 | threaded pin |
| 82 | K200L6.04.082 | leaflet |
| B4 | K200L6.04.0B4 | leaflet |
| 100 | K200L6.04.100 | Group pianetto toupiŠ (29-49) |
| 101 | K200L6.04.101 | horizontal pressure |
| 102 | K200L6.04.102 | Group Shopping mortiser |
| 103 | K200L6.04.103 | vertical pressure |
| Pag.5 | ||
| 2 | K200L6.05.002 | Block limit 2 |
| 3 | K200L6.05.003 | Shopping Guide x K200L6 |
| 4 | K200L6.05.004 | block K200L6 |
| 6 | K200L6.05.006 | Cutting plane |
| 7 | K200L6.05.007 | Holder sawn |
| 9 | K200L6.05.009 | Clamping sleeve |
| 10 | K200L6.05.010 | Holder |
| 12 | K200L6.05.012 | Riving knife x Baby-Komp. 200 L6 |
| 13 | K200L6.05.013 | handle |
| 14 | K200L6.05.014 | Upper blade guard x Baby Kompacta 200 L6 |
| 15 | K200L6.05.015 | blade guard X Baby Kompacta 200 L6 |
| 16 | K200L6.05.016 | Inside the wooden blade cover |
| 17 | K200L6.05.017 | Inside the wooden blade cover |
| 18 | K200L6.05.018 | Inside the wooden blade cover |
| 19 | K200L6.05.019 | Inside the wooden blade cover |
| 21 | K200L6.05.021 | Support plate |
| 24 | K200L6.05.024 | Carter upper K200L6 |
| 25 | K200L6.05.025 | Carter lower K200L6 |
| 33 | K200L6.05.033 | Protractor team cart |
| 36 | K200L6.05.036 | Cap foot bitten K200L6 |
| 37 | K200L6.05.037 | bracket |
| 38 | K200L6.05.038 | foot vise |
| 41 | K200L6.05.041 | threaded pin |
| 42 | K200L6.05.042 | Holder bars trolley travel |
| 81 | K200L6.05.081 | leaflet |
| 82 | K200L6.05.082 | Lever x Baby Kompacta 200L6 |
| 83 | K200L6.05.083 | Bearing 6200 2RS d.10x26x8 |
| 88 | K200L6.05.088 | Interr.generale K200L6 |
| 95 | K200L6.05.095 | Finned ferrule VL60x30 1.5 |
| 100 | K200L6.05.100 | Group sliding K200L6 |
| 101 | K200L6.05.101 | Pressure unit K200L6 |
| 102 | K200L6.05.102 | Group angle goniometer K200L6 |
| 103 | K200L6.05.103 | Protective plastic blade K200L6 |
| 104 | K200L6.05.104 | Group shelf full Shopping guide |
| Pag.6 | ||
| 2 | K200L6.06.002 | Spacer x Baby Kompacta 200 L6 |
| 3 | K200L6.06.003 | Box button x Baby Kompacta 200 L6 |
| 4 | K200L6.06.004 | electric board |
| 5 | K200L6.06.005 | Label grounding |
| 6 | K200L6.06.006 | Spacer x Baby Kompacta 200 L6 |
| 7 | K200L6.06.007 | Box cover button x BabyK.200L6 |
| 81 | K200L6.06.081 | Safety Switch |
| 88 | K200L6.06.088 | Switch Assembly |
| Pag.7 | ||
| 1 | K200L6.07.001 | door |
| 2 | K200L6.07.002 | Right side x Baby Kompacta 200L6 |
| 3 | K200L6.07.003 | angular |
| 4 | K200L6.07.004 | bottom plate |
| 5 | K200L6.07.005 | Left side x Baby Kompacta 200L6 |
| 6 | K200L6.07.006 | Cover x Baby Kompacta 200L6 |
| 500 | KO200L6/19LT1 | Set 3 Knives |
| 501 | 0242AWZ36 | Circular Blade mm 250Z40 |
| 502 | ACC.33/2 | 6 pcs. mortiser tool set |
