Compa-OMS Spare Parts for Portable Saws SLIDER 255X

Compa-OMS Spare Parts for Slider Compound Mitre Saw SLIDER 255X

COMPA-OMS authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues forSlider Compound Mitre Saw SLIDER 255X.

In the following table, look for the model of the Portable Saws and their spare part.

MITRE SAW SLIDER 255 X
1	255X/001	Sidebar x 255X
2	255X/002	Rubber feet x 255X
3	255X/003	Flat washer x 255X d.4
4	255X/004	Screw Pan Head x 255X M4X10
5	255X/005	Flat washer x 255X d.10
6	255X/006	Wavy spring washer x 255X d.10
7	255X/007	Nylock nut M10 x 255X
8	255X/008	Adjustment screw cross x 255X M5X20
9	255X/009	Base x 255X
10	255X/010	Tapping screw x 255X
11	255X/011	Additional leg x 255X
12	255X/012	Locking knob x 255X
13	255X/013	Spring x 255X
15	255X/015	Column locking x 255X
16	255X/016	Screw Pan Head Phillips x 255X
17	255X/017	Fixing plate x 255X
18	255X/018	Nylock nut M6 x 255X
19	255X/019	Fixing spring x 255X
20	255X/020	Screw x 255X
21	255X/021	Table x 255X
22	255X/022	Graduated indicator x 255X
23	255X/023	Screw post x 255X M10x45
24	255X/024	Left paddle x 255X
25	255X/025	Right flipper x 255X
26	255X/026	Circlip tree x 255X d.6
27	255X/027	Tree x 255X
28	255X/028	Knob x 255X
29	255X/029	Support roller x 255X
30	255X/030	Roller x 255X
31	255X/031	Platelet limitation
32	255X/032	Flat washer x 255X d.5
33	255X/033	Nylock nut M5 x 255X
34	255X/034	Clamping ring x 255X
34-37	255X/034-37 C	(USE CODE 255X / 204)
35	255X/035	Clamping plate x 255X
36	255X/036	Knob x 255X
37	255X/037	Mast mounting x 255X
38	255X/038	Help support x 255X
39	255X/039	Flat washer x 255X d.6
40	255X/040	Adjustment screw hex x 255X
41	255X/041	Adjustment screw hex x 255X
42	255X/042	Tree Connection x 255X
43	255X/043	Nut M6 x 255X
44	255X/044	Support base x 255X
45	255X/045	Indicator x 255X
46	255X/046	Tapping screw x 255X ST3X8
47	255X/047	Laser x 255X
48	255X/048	Support laser x 255X
49	255X/049	Spring pin x 255X d.6X45
50	255X/050	Tree x 255X
51	255X/051	Spring x 255X
52	255X/052	Front Width x 255X
53	255X/053	Pivot shaft x 255X
54	255X/054	O-ring x 255X
55	255X/055	Rubber stopper x 255X
56	255X/056	Knob d.22 M6 255X
57	255X/057	Drawbar main x 255X
58	255X/058	Traction rod sliding guide
59	255X/059	Spring washer x 255X d.4
60	255X/060	Cover plate x 255X
61	255X/061	Ring closing x 255X
62	255X/062	Washer x 255X
63	255X/063	Linear bearing x 255X
64	255X/064	Bushing bearing x 255X
65	255X/065	Support block x 255X
66	255X/066	Label graduated x 255X
67	255X/067	Nut M8 x 255X
68	255X/068	Nail helical internal hexagon
69	255X/069	Header x 255X
70	255X/070	Spring x 255X
71	255X/071	Locking knob d.40 M10x20 255X
72	255X/072	Rear base x 255X
73	255X/073	Clamp cables x 255X
74	255X/074	Washer 255X x d.12
75	255X/075	Washer 255X x d.12
76	255X/076	Nylock nut x 255X d.12
77	255X/077	Washer x 255X d.8
78	255X/078	Upright locking x 255X
79	255X/079	Locking knob x 255X
80	255X/080	Spring x 255X
81	255X/081	Screw x 255X
82	255X/082	Screw x 255X M8X20
83	255X/083	Washer x 255X
84	255X/084	Upper flange x 255X
86	255X/086	Bottom flange x 255X
87	255X/087	Circlip shaft 255X x D.48
88	255X/088	Guarding x 255X
89	255X/089	Aluminum protection x 255X
90	255X/090	Aluminum rivet x 255X d.3x10
91	255X/091	Screw Pan Head Phillips x 255X
92	255X/092	Spring x 255X
93	255X/093	Post x 255X
94	255X/094	Key x 255X 6X6X16
95	255X/095	Hat bearing x 255X
96	255X/096	Bearing x 255X 6004
97	255X/097	Circlip hole 255X x D.42
98	255X/098	Circlip shaft 255X x d.20
99	255X/099	Gear x 255X
100	255X/100	Circlip shaft 255X x d.17
101	255X/101	Needle Bearing HK1210 x 255X
102	255X/102	Left handle x 255X
104	255X/104	Capacitor x 255X
105	255X/105	Switch x 255X
106	255X/106	Spring x 255X
107	255X/107	Locking key post x 255X
108	255X/108	Connecting lock button
109	255X/109	Connecting lock button
110	255X/110	Spring x 255X
111	255X/111	Horizontal connection x 255X
112	255X/112	Left handle x 255X
113	255X/113	Tapping screw x 255X ST4X20
114	255X/114	Screw x 255X
115	255X/115	Connecting bar higher x 255X
116	255X/116	Rivet x 255X
117	255X/117	Screw x 255X
118	255X/118	Connecting bar intermediate x 255X
119	255X/119	Washer x 255X
120	255X/120	Lever movement Carter 255X
121	255X/121	Pin button lock blade 255X
122	255X/122	Spring pin x 255X d.3X20
123	255X/123	Spring x 255X
124	255X/124	Block clash x 255X
125	255X/125	Protection plate x 255X
126	255X/126	Guarding top x 255X
130	255X/130	Galletto metal M6 255 X
131	255X/131	Knob d.22 M6x50
132	255X/132	Washer rotor 255 X
133	255X/133	Feltrino 255 X
137	255X/137	Rotor 255 X
139	255X/139	Front baffle engine
142	255X/142	Wound stator 255 X
146	255X/146	case charcoals
147	255X/147	Couple brushes 255X
148	255X/148	Cap for charcoals 255 X
150	255X/150	Motor fan cover 255 X
156	255X/156	Transformer for laser
158	255X/158	Stop. 0-1 command laser
159	255X/159	Support sacc.racc.truccioli 255 X
200	255X/200	Group acc.completo 255X (manu.-tube-gons
201	255X/201	Motor unit complete 255 X
202	255X/202	Group housing complete 255 X
203	255X/203	Lever M8x65
204	255X/204	Vertical clamp 255 X
205	255X/205	Group tree saw assembled 255X
