Bosch Spare Parts for Angle Grinder GWS 880
€3.10
Tax included
Bosch Spare Parts for Angle Grinder GWS 880
We have the original Spares BOSCH for Angle Grinder GWS 880 - 3601C96005. the diagram, parts list and tool repair that help you need to get your tools running like new again.Fix Your Angle Grinder GWS 880. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Bosch Spare Parts for Angle Grinder GWS 880
Fix Your Angle Grinder GWS 880 - 3601C96005. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the Angle Grinder and the respective parts of the code.
| Angle Grinder GWS 880/3 601 C96 005 | ||
| # | Part Num. | Description |
| 1 | 1619P10959 | Motor Housing |
| 2 | 1619P10953 | Field 220-240V |
| 3 | 1619P10952 | Armature 220-240V |
| 4 | 1607200326 | Switch |
| 5 | 1604460312 | Power supply cord CN 2,65m 2 x 0,75mm H05 W-F |
| 6 | 2600703012 | Grommet Ø6,5-Ø6,9x95 MM |
| 7 | 1601302017 | Fastening Clamp |
| 8 | 1619P32505 | Nameplate |
| 9 | 1619P11343 | Manufacturer's nameplate GWS 880 |
| 12 | 1619P13846 | Suppression Filter |
| 13 | 1619P08829 | groove ball bearing |
| 14 | 1619P13103 | groove ball bearing |
| 16 | 1619P01811 | Brush Holder |
| 17 | 1604652013 | Spiral Spring |
| 18 | 1619P11487 | Compression Spring |
| 22 | 1619P10968 | Adjusting Slide |
| 23 | 1619P10969 | Switch Button |
| 25 | 1619P13558 | Housing Cover |
| 26 | 1600502023 | Intermediate Ring |
| 27 | 1600206025 | Rubber Ring |
| 29 | 1619P10970 | Air-Deflector Ring |
| 30 | 1619P14139 | Air Distributor |
| 32 | 1619P06419 | Grinding Spindle M 14, SW 17 |
| 35 | 1619P02821 | Shim 0,1 MM |
| 35 | 1619P02822 | Shim 0,2 MM |
| 36 | 1619P00987 | Washer |
| 37 | 1600100033 | Cover Disc |
| 41 | 1600910018 | Needle bearing Ø8xØ12x8 MM |
| 45 | 2915011007 | Hex Nut DIN 934-M6-8-A |
| 47 | 2609110052 | Special Screw |
| 48 | 1619P00220 | Torx Oval-Head Screw 3x10 |
| 49 | 1619P11118 | Thread-forming tap. Screw |
| 50 | 1619P00105 | Torx Oval-Head Screw 4x20 |
| 55 | 1619P01066 | Torx Oval-Head Screw 4x25 |
| 80 | 1619P09390 | Cover Disc |
| 108 | 1619P02866 | Shrinkable Tube |
| 650/1 | 1619P10681 | Auxiliary Handle |
| 650/2 | 1603345043 | Round Nut M14 |
| 650/3 | 1619P08927 | Pin-Type Face-Wrench |
| 650/5 | 2605703014 | Clamping Flange Ø22,3xØ42 MM |
| 650/5/2 | 1600210039 | O-Ring 20,35x1,78 MM |
| 651 | 1600A00XU6 | Protective Cover Ø115 MM SILVER |
| 810 | 1619P11715 | Carbon-Brush Set |
| 828 | 1619P07452 | Bearing Flange |
| 831 | 1619P12186 | Gear Housing |
| 838 | 1619P14111 | Set Of Gears |
| 840 | 1619P12188 | Push Button |
| 858 | 2910641081 | Oval-Head Screw DIN7985-M3,5x5-4.8-H |
| 894 | 1615430020 | Grease Tube 225 ML |
| 895 | 1605430003 | Grease Tube 225 ML |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s BOSCH websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to BOSCH brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Bosch GWS 880 - 3601C96005
10 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N BOSCH:
- BOSCH S/N START WITH (0) or (3) AND HAVE 10 DIGITS
