Bosch Spare Parts for Angle Grinder GWS 22-230 LVI
€2.09
Tax included
Bosch Spare Parts for Angle Grinder GWS 22-230 LVI
Bosch genuine replacement parts for to replace broken parts for to fix Angle Grinder GWS 22-230 JH - 3601H82M01.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Bosch Spare Parts for Angle Grinder GWS 22-230 LVI
Bosch genuine replacement parts for to replace broken parts for to fix Angle Grinder GWS 22-230 JH - 3601H82M01.
In the following table, look for the model of the Angle Grinder and the respective parts of the code.
| Angle Grinder GWS 22-230 LVI/3 601 H91 C00 | ||
| # | Part Num. | Description |
| 1 | 1605108264 | Motor Housing BLUE |
| 2 | 160422053X | Field |
| 6 | 1600703036 | Grommet Ø10,5-Ø11,0x100 MM |
| 7 | 1601302018 | Fastening Clamp |
| 9 | 160111C281 | Manufacturer's nameplate GWS 22-230 LVI |
| 13 | 1600905034 | groove ball bearing 9x26x8 |
| 14 | 1600905035 | groove ball bearing 12x37x12 |
| 23 | 1605500266 | Cover BLACK |
| 24 | 1605132155 | Handle BLUE |
| 25 | 160312305U | Grinding Spindle |
| 28 | 1600210033 | O-Ring 79,0x1,78 MM |
| 29 | 1600210045 | O-Ring 8,0x1,0 MM |
| 30 | 1600591041 | Air Distributor |
| 31 | 160059105U | Air-Deflector Ring |
| 32 | 1600290019 | Retaining snap ring |
| 33 | 1600290064 | Rotary shaft lip seal 16 MM BLUE |
| 34 | 1600190020 | Shim 0,15 MM THICK |
| 34 | 1600190021 | Shim 0,3 MM THICK |
| 34 | 1600190022 | Shim 0,1 MM THICK |
| 34 | 1600190037 | Shim 0,2 MM THICK |
| 34 | 1600190038 | Shim 0,25 MM THICK |
| 34 | 1600190039 | Shim 0,35 MM THICK |
| 34 | 1600190040 | Shim 0,4 MM THICK |
| 35 | 1600205034 | Felt Washer |
| 37 | 1600290036 | Seal Ring BLACK |
| 38 | 1600206037 | Rubber Ring |
| 43 | 1605500264 | Sealing cap BLACK |
| 44 | 1605500265 | Sealing cap BLACK |
| 45 | 1603300019 | Hex Nut M10, SW14 |
| 50 | 1607001007 | Rotational Speed Sensor |
| 51 | 1600200031 | Plain bearing Ø14 MM |
| 60 | 1603435023 | Thread-forming tap. Screw TT M5x18 MM |
| 61 | 1603490005 | Torx Oval-Head Screw |
| 63 | 1603410014 | Pan head screw M4x10 MM |
| 64 | 2603490021 | Torx Oval-Head Screw 4x12 |
| 65 | 2603490023 | Torx Oval-Head Screw 4x20 |
| 66 | 2910211019 | Tapping Screw DIN 7971-ST3,9x16-F |
| 68 | 1601006011 | Sealing Plate |
| 75 | 1600290060 | Damper |
| 76 | 1603414025 | Collar Screw |
| 81 | 1600190048 | Magnet |
| 131 | 160111C282 | Manufacturer's nameplate GWS 22-230 LVI |
| 651 | 1600A00Z9L | Protective Cover |
| 660 | 1602025051 | Auxiliary Handle M14 BLACK |
| 802 | 1607000C4K | Assembly |
| 803 | 1604011297 | Armature 230V |
| 804 | 1607000C15 | On-Off Switch |
| 805 | 1607000227 | Power supply cord EU 4,15m 2 x 1,0mm H07 RN-F |
| 808 | 1601106940 | Nameplat |
| 810 | 1607014171 | Carbon-Brush Set |
| 810 | 1607000480 | Carbon-Brush Set 10 x 1 607 014 171 |
| 816 | 1604336053 | Brush Holder |
| 821 | 1607000C17 | Gear Housing |
| 822 | 1607000C24 | Bearing Flange Ø230 MM |
| 826 | 1607000429 | Bevel Gear Set |
| 835 | 1606610150 | Fan |
| 840 | 1607000431 | Push-Button |
| 846 | 1607000432 | Retaining Washer |
| 848 | 1600119010 | Retaining clip |
| 850 | 1600905026 | groove ball bearing 17x40x12 |
| 851 | 2600910001 | Needle-Roller Bearing Ø14 MM |
| 880 | 1607233552 | Electronics Module |
| 890 | 1600210039 | O-Ring 20,35x1,78 MM |
| 891 | 1602025022 | Auxiliary Handle M14 BLACK |
| 892 | 1607950061 | Pin-Type Face-Wrench |
| 893 | 2605703014 | Clamping Flange Ø22,3xØ42 MM |
| 894 | 1603345043 | Round Nut M14 |
| 896 | 1603340027 | Fast Locking Flange M14, SDS-CLIC |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s BOSCH websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to BOSCH brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
