Ama Spare Parts for Chainsaw AMX 45.16
€3.97
Tax included
Ama Spare Parts for Chainsaw AMX 45.16
We are AMA Garden original spare parts Dealers at low at unbeatable prices and a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Petrol Chainsaw AMX 45.16 - 92607.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Ama Spare Parts for Chainsaw AMX 45.16
We are AMA Garden original spare parts Dealers at low at unbeatable prices and a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Petrol Chainsaw AMX 45.16 - 92607.
Open PDF diagram in this page to check parts you need for your chainsaw AMA.
| Chainsaw AMX 45.16 - Base Pag.1 | ||
| # | Part Num. | Description |
| 1 | Standard | Tapping screw ST4×10 |
| 2 | 95107 | Bottom cover |
| 3 | 95108 | Switch |
| 4 | Standard | Extinction conductor |
| 5 | Standard | Ground lead |
| 6 | 63833 | Primer bulb |
| 7 | Standard | Pin 3×25 |
| 8 | 95109 | Throttle trigger spring |
| 9 | 95134 | Throttle trigger |
| 10 | 57513 | Shock rubber gland |
| 11 | 63788 | Rear handle fixing screw |
| 12 | 57496 | Dust cover |
| 13 | 95135 | Rear handle |
| 14 | 79422 | Oil nozzle |
| 15 | 79415 | Primer Pump line (2.5x5x155) |
| 16 | 57507 | Fuel filter |
| 18 | 57506 | Fuel tube |
| 19 | 63771 | Balancer |
| 20 | 63885 | Balancer seat |
| 21 | 88190 | Shock rubber |
| 22 | 95136 | Oil tank cap assembly |
| 26 | 95137 | Flow guiding cover |
| 27 | 95138 | Starter assembly |
| 28 | 95139 | Start coil spring |
| 29 | 95140 | Start plate |
| 30 | 95141 | Easy start-coil spring |
| 31 | 95142 | Easy start-coil spring cover |
| 32 | Standard | Plate washer 5 |
| 33 | Standard | Tapping screw ST5×16 |
| 34 | 95143 | Starter handle |
| 36 | 64060 | Eyelet |
| 38 | 95144 | Start housing |
| 39 | 95145 | Start cover nameplate |
| 40 | Standard | Screw M5×16 (GB/T2672) |
| 41 | 95146 | Oil tank cap assembly |
| 44 | 60339 | Chain catcher |
| 45 | 58212 | Anti-vibration spring |
| 46 | 64074 | Spring base |
| 47 | 95147 | Return spring |
| 48 | 95148 | Return spring cover |
| 49 | 95149 | Front handle guard screw |
| 50 | 95150 | Front handle guard |
| 51 | 95151 | Cylinder shield assembly |
| 52 | Standard | Tapping screw ST3.5×6 (GB/T845) |
| 53 | 95152 | Top cover air guide sheet |
| 54 | 95153 | Aluminium septum for crankcase |
| 56 | 95154 | Clip |
| 57 | 95155 | Cylinder shield |
| 58 | 95156 | Air filter cover |
| 59 | Standard | Screw M5×10 |
| 60 | 95157 | Aluminium septum for cylinder shield |
| 61 | 95158 | Idle adjusting guide set |
| 62 | 88185 | Throttle lever retaining bracket |
| 63 | 95159 | Choke knob |
| 64 | 95160 | Clutch cover assembly |
| 65 | Standard | Screw M4×8 |
| 66 | 95161 | Tensioner cover plate |
| 67 | 95162 | Brake spring cover |
| 68 | Standard | Pin 3.05×9 |
| 69 | 95163 | Main level |
| 70 | Standard | Pin 3×9 |
| 71 | 95164 | Secondary pull-rod |
| 72 | 95165 | Brake control rod |
| 73 | 95166 | Brake strap |
| 74 | 88196 | Secondary brake spring |
| 75 | 64046 | Brake spring |
| 76 | 95167 | Clutch cover |
| 77 | 95168 | Tensioner screw |
| 78 | 95169 | Tensioner block |
| 79 | 95170 | Passive bevel gear |
| 80 | 95171 | Drive bevel gear |
| 81 | 95172 | Lengthen nut combination |
| 82 | Standard | Plate washer 11 |
| 83 | Standard | M8 flang nut |
| 84 | 95173 | Nut plate |
| 85 | 95174 | Rear handle cover |
| 86 | 95175 | Throttle trigger lock-out |
| 87 | 95176 | Throttle rod |
| 88 | 95177 | Front handle |
| 89 | 88176 | Small dust cover |
| 90 | 84916 | 16'' Oregon bar |
| 57241 | 16'' ama bar | |
| 91 | 79541 | Oregon Saw chain 66E |
| 61298 | AMA Saw chain 66E | |
| 92 | 55087 | Guide bar cover 16'' |
| Chainsaw AMX 45.16 - Engine Pag.2 | ||
| # | Part Num. | Description |
|
1
|
95178
|
Nut M8×1 |
|
2
|
95179
|
Rotator |
|
3
|
63818 | Semi-circle key |
|
4
|
Standard
|
Screw M5×20 |
|
5
|
95180 | Ignition |
|
6
|
90456
|
Pressure nozzle |
|
7
|
63813 | Circlip |
|
8
|
90409
|
Pressure tube |
|
9
|
95181
|
Idle adjusting guide set |
|
10
|
58216 | Needle bearing ring |
|
11
|
Needle bearing φ11×φ15×12.5 | |
|
12
|
57876 | Circlip |
|
13
|
57873
|
Piston pin |
|
14
|
57875 | Piston |
|
15
|
57874 | Piston ring |
|
16
|
57499 | Cylinder gasket |
|
17
|
95182
|
Cylinder |
|
18
|
Standard
|
Screw M5×12 |
|
19
|
Standard
|
Nut M5 |
|
20
|
Standard
|
Lock washer 5 |
|
21
|
95183
|
Muffler cover |
|
22
|
95184
|
Muffler |
|
23
|
57518 | Muffler gasket |
|
24
|
64078
|
Muffler connecting screw |
|
25
|
12207
|
Spark plug |
|
26
|
A45.1106.0101
|
Spark plug cap |
|
27
|
57497 | Air intake tube sealing plate |
|
28
|
57498
|
Intake pipe |
|
29
|
Standard
|
Screw M5×12 |
|
30
|
64068
|
Carburettor supporting frame |
|
31
|
58223
|
Sealing plate of air intake support |
|
32
|
64077
|
Air intake flange |
|
33
|
88180
|
Support ring |
|
34
|
95185
|
Air cleaner foam |
|
35
|
95186
|
Air filter lock nut |
|
36
|
95187
|
Air filter cover |
|
37
|
Air filter | |
|
38
|
Standard
|
Screw M5×50 |
|
39
|
Standard
|
Plate washer 5 |
|
40
|
88183
|
Cushion of air intake socket |
|
41
|
95189
|
Air filter base |
|
42
|
57511
|
Carburettor |
|
47
|
Standard
|
Screw M5×12 |
|
48
|
Standard
|
Double-screw bolt M8X45-8.8 |
|
49
|
95190
|
Tensioner cover |
|
50
|
Standard
|
Screw M4×10 |
|
51
|
57523 | Oil pump |
|
52
|
57524 | Oil pipe nozzle |
|
53
|
73824 | Oil tube |
|
54
|
57633 | Oil filter |
|
56
|
55072 | Turbine |
|
57
|
57532 | Needle bearing φ12×φ15×14.5 |
|
58
|
57795 | Sprocket 0.325 . 7 |
|
59
|
88189 | Clutch drum |
|
60
|
57531 | Washer for clutch |
|
61
|
57529 | Clutch |
|
62
|
57530 | Clutch spring |
|
65
|
58197
|
Cover plate |
|
66
|
Standard
|
Screw M4×14 |
|
67
|
63862 | Sponge transition coil |
|
68
|
88178 | Oil sealing |
|
69
|
64073 | Cushion socket |
|
70
|
95191
|
Right crankcase |
|
71
|
95192
|
Top cover support |
|
72
|
57893
|
Right shock block |
|
73
|
88179
|
Left shock block |
|
75
|
95193
|
Dust cover |
|
76
|
95194
|
Rubber gasket |
|
77
|
95195
|
Crankshaft |
|
78
|
95196
|
Crankcase gasket |
|
79
|
Standard
|
Pin 5×10 |
|
80
|
Standard
|
Bearing |
|
81
|
95197
|
Left crankcase |
|
82
|
Standard
|
Ring 35 |
|
83
|
88177
|
Oil sealing |
|
84
|
Standard
|
Screw M5×25 |
|
85
|
88181
|
Oil seal damper |
|
86
|
Standard
|
Lock washer 4 |
|
87
|
Standard
|
Screw M4×8 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Ama websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Ama brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Ama AMX 45.16 - 92607
