Ama Spare Parts for Self-Propelled Lawnmower LTA 48
€736.40
Tax included
Ama Spare Parts for Self-Propelled Lawnmower LTA 48
Distribution and Sale at attractive prices of AMA Garden Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Self-Propelled Lawnmower LTA 48 Art. 84915.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Ama Spare Parts for Self-Propelled Lawnmower LTA 48
Distribution and Sale at attractive prices of AMA Garden Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Self-Propelled Lawnmower LTA 48 Art. 84915.
In the following table, look for the model of the Lawnmower and the respective parts of the code.
| Self-Propelled Lawnmower LTA 48 Art. 84915 | ||
| Spare Parts for Engine T675 | ||
| # | Part Num. | Description |
| 1 | Foam Pipe | |
| 2 | 88433 | E Type Self-propelled Lever |
| 3 | 88434 | E Type Stop Lever |
| 5 | 88448 | Brake and Self-Propelled Cable |
| 7 | 88451 | Rope Guide |
| 9 | 88452 | Triangle Knob |
| 12 | 88453 | G Type Lower Handrail(AL480) |
| 13 | 88454 | Fastener |
| 17 | 88455 | G Type Upper Handrail |
| 18 | 88456 | T675 Engine |
| 19 | 88449 | Outside Cover for C Type 11" Wheel Hub |
| 20 | 88457 | R8-2RS bearing |
| 21 | 88450 | C Type 11" Wheel Assy |
| 23 | 88458 | Inner Cover for C Type 11" Wheel Hub |
| 25 | 88459 | AL480 Rear Drive Shaft Assy(GT) |
| 26 | 88460 | Bearing |
| 28 | 88461 | Shaft for Rear Discharge Cover |
| 29 | 88462 | Rear Discharge Cover |
| 30 | 88463 | Spring for Rear Discharge Cover |
| 32 | 88464 | right decoration board for chassis |
| 33 | 88465 | 19"aluminum chassis |
| 35 | 88441 | Outside Cover for C Type 8" Wheel Hub |
| 36 | 88440 | C Type 8" Wheel Assy |
| 37 | 88466 | Front bumper (steel pipe) |
| 39 | 88467 | Front Drive Shaft Assy |
| 40 | 88468 | Pressure plate for front drive |
| 42 | 88469 | Pull rod for height adjustment |
| 43 | 88470 | Ventilation plate |
| 45 | 88471 | Pressure plate for rear drive |
| 46 | 88472 | spring for pull rod |
| 48 | 88473 | B type Height Adjuster Board |
| 50 | 88474 | Small Belt Wheel |
| 51 | 88475 | Long Key for Crankshaft |
| 52 | 88476 | Short Washer for Blade Adapter |
| 53 | 88439 | Blade Adapter Assy(European standard) |
| 54 | 88438 | Fan |
| 55 | 88437 | 408 A type blade |
| 56 | 88436 | Blade Washer |
| 57 | 88435 | Hex Flange Face Bolt |
| 58 | 88477 | Rear baseplate |
| 59 | 88478 | Left decoration board for chassis |
| 60 | 88479 | Mulching Plug |
| 61 | 88480 | Belt cover |
| 64 | 88481 | Baseplate for rubber dust shield |
| 65 | 88482 | Rubber dust shield |
| 66 | 88442 | 70L Fabric Bag Assy |
| 67 | 88483 | 70L Plastic Bag Cover |
| 68 | 88484 | Ventilation board for bag cover |
| 69 | 88485 | Protective cap for handling |
| 70 | 88443 | V type Belt |
| 72 | 88486 | Ratchet Wheel Washer |
| 73 | 88444 | Small Straight Gear(Ratchet Wheel L) |
| 74 | 88445 | Ratchet Pin |
| 75 | 88446 | Small Straight Gear(Ratchet Wheel R) |
| 76 | 88447 | GT transmission Assy |
| 77 | 88487 | Self-propelled Spring |
| 78 | 88488 | C type height adjsut handle |
| 81 | 88489 | frame Assy for 70L half- plastic Bag |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Ama websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Ama brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Ama LT 48 - 84915
