Ama Spare Parts for Hand Blower Vac AG4 BLV

€9.47
Tax included

Ama Spare Parts for Hand Blower Vac AG4 BLV

AMA Garden repair service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Hand Blower Vac AG4 BLV - 90005.
ITEM CODE: 56432
Quantity
Only Demand Call Us Before

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Ama Spare Parts for Hand Blower Vac AG4 BLV

AMA Garden repair service center

 and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Hand Blower Vac AG4 BLV - 90005.

In the following table, look for the model of the Hand Blower and the respective parts of the code.
Hand Blower Vac AG4 BLV - 90005

AMA Garden Hand Blower Vac AG4 BLV - 90005
A Pag.1
# Part Num. Description
1 RSOF1 Pipe (2)
2 RSOF3 Pipe (1)
3 Screw M5x10
4 RSOF10 Switch Carapace
5 Screw M5x10
6 RSOF11 Switch
7 Screw M5x20
8 90192 Nut M8LH
9 90193 Comminute Board
10 90156 Washer
11 90157 Impeller
12 76273 Washer
13 90158 Valute Case
14 90159 Spring
15 90160 Lock Handle
16 Stop wire
17 76276 Stop Switch
18 90161 Control Handle
19 90162 Baffle
20 Screw ST4.2x9.5
21 90163 Damping Post
22 90164 Underpining
23 Nut M5
24 90165 Spring
25 90166 Fuel Throttle
26 90167 Fuel pipe
27 90054 Fuel Pipe
28 88556 Plug
29 88857 Filter
30 90168 Chain
31 Airvalve
32 End cover
33 Sealing washer
34 Lid
35 Fuel tank lid
36 90169 Spark plug cover
37 90170 Block
38 90171 Starter
39 90172 Outside control
40 90267 Protection
41 90268 Inside control
42 RSOF30 Screw
43 Sealing washer
44 RSOF42 Spring
45 RSOF49 Spring
46 90173 Pipe (1)
47 90174 Pipe (2)
48 90175 Collecting Pipe
49 90176 Collecting Bag
50 Screw M5x10
51 90177 Protection
53 Screw M5x16
54 90178 Connection
55 90179 Primer
56 90180 Connection
57 90054 Fuel Pipe
58 90181 Protection
59 90182 Fuel Tank
B Pag.2
1 90041 Outside Cover
2 90042 Filter Net
3 Screw M5x75
4 Screw ST2.9x6.5
5 Gasket 3
6 90043 Choke
7 90044 Inside Cover
8 76220 Choke Handle
9 90045 Separator
10 90046 Air check valve
11 90047 Air check valve bracing
12 90048 O-ring
13 90049 Air check valve
14 90051 Returning oil pipe
15 90052 Windpipe
16 90053 Carburetor
17 90054 Fuel pipe (0.115 m)
18 90056 Gasket
19 90057 Gasket
20 Screw M5x20
21 90058 Admitting Pipe
22 90061 Admitting Gasket
23 90062 Rocker pin
24 Screw M5x16
25 90063 Cylinder cover
26 90064 Cylinder cover gasket
27 56432 Spark plug
28 90066 Spring
29 90067 Gasket
30 90068 Tie-in
31 90069 Adjust Nut
32 90070 Jib Seat
33 90071 Rocker pin
34 90072 Jib
35 90073 Jib sealing gasket
36 90074 Side cover
37 90075 Side cover gasket
38 90076 Pin
39 90077 Below Rocker
40 90078 Cam and gear shaft
41 90079 Cam wheel
42 90080 Output Valve
43 90081 Input Valve
44 90082 Spring
45 90083 Spring seat
46 90084 Cylinder
47 90085 First piston ring
48 90086 Second piston ring
49 90087 Oil ring
50 90088 Air check valve
51 90089 Piston
52 90090 Needel bearing
53 90091 Piston Pin
54 90092 Ring
55 90093 Crank shaft
56 Bearing 6001-RS/P5
57 90094 Gear
58 90095 Seal
59 90096 Oil pipe
60 90097 Ball
61 90098 Crank case
62 90099 Reed
63 90131 Board
64 Gasket 5
65 90132 Gasket
66 90133 Screw
67 90134 Gasket
68 Gasket 4
69 90135 Board
70 Screw M5x30
71 Screw M4x10
72 90136 Sump
73 90137 Dipstick reality
74 Screw M5x16
75 O-Ring 14x3
76 90138 Oiling pipe
77 90139 Dipstick
78 O-Ring 20x2.65
79 Bearing 6001/p6
80 90183 Check ring
81 90184 Seal
82 90185 Fly Wheel
83 90186 Coil
84 Screw M4x20
85 90187 Parking
86 90146 Support pipe
87 90147 Start Reel
88 Screw M5x40
89 Gasket 5
90 90148 Muffler
91 90149 Gasket
92 90188 Heat Insulation mat
93 Screw M5x16
94 90189 Starter
95 Screw M5x16
96 90189 High Voltage cap
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Ama websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Ama brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
