Ama Spare Parts for Multifunction PLAYCUT 33 cc - 89810
€1.34
Tax included
Ama Spare Parts for Multifunction PLAYCUT 33 cc - 89810
We have the original Ama Spare Parts for Multifunction PLAYCUT 33 cc, the diagram, parts list and tool repair that help you need to get your tools running like new again.Fix Your Multifunction PLAYCUT 33 cc - 89810. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Ama Spare Parts for Multifunction PLAYCUT 33 cc - 89810
Fix Your Multifunction PLAYCUT 33 cc - 89810. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the Bruschcutter and the respective parts of the code.
| MULTIFUNCTION PLAYCUT 33 cc - 89810 - Engine Pag.1 | ||
| # | Part Num. | Description |
| 1 | 79840 | Screw axes |
| 2 | 79841 | Wave washer |
| 3 | 79842 | Clutch |
| 4 | 79843 | Washer B |
| 5 | Standard | M5x20 screw |
| 6 | 79844 | Fly wheel cover |
| 7 | Standard | Round pin B5x10 |
| 8 | 79845 | Wind guid board |
| 9 | Standard | M8 nut |
| 10 | Standard | Spring washer 8 |
| 11 | Standard | Flat washer 8 |
| 12 | 79847 | Fly wheel |
| 13 | Standard | M5x30 screw |
| 14 | 79848 | Front-half crankshaft case |
| 15 | 79849 | Ignition coil |
| 16 | 79850 | Crankshaft gasket |
| 17 | 79810 | Oil seal TC12x22x7 |
| 18 | 79851 | Bearing 6201 |
| 19 | 7982 | Half-round key 3x5x13 |
| 20 | 79853 | Crankshaft assy |
| 21 | 79854 | Back-half crankshaft case |
| 22 | 79855 | Needle bearing |
| 23 | 79856 | Piston |
| 24 | 79857 | Piston pin |
| 25 | 79858 | Piston pin check ring |
| 26 | 79859 | Piston ring |
| 27 | 79860 | Cylinder gasket |
| 28 | 79861 | Cylinder - EUII |
| 29 | 79862 | Muffler gasket |
| 30 | 79863 | Muffler - EUII |
| 31 | Standard | M5x12 screw |
| 32 | 92444 | Muffler cover |
| 33 | Standard | Flat washer 5 |
| 34 | Standard | M5x55 screw |
| 35 | 79968 | Inlet gasket |
| 36 | 79864 | Inlet pipe |
| 37 | 79869 | Carburetor gasket |
| 38 | 79969 | Carburetor |
| 39 | 79865 | Starter catch plate |
| 40 | 79866 | Starter sede gasket |
| 41 | 79867 | Easy-start starter |
| 42 | Standard | M5x25 screw |
| 43 | 79868 | Fuel tank holding plate |
| 44 | 79870 | Holding plate rubber gasket |
| 45 | 92451 | Air filter bese |
| 46 | 92454 | Air filter bracket |
| 47 | Standard | Spring washer 5 |
| 48 | 92456 | Air filter sponge |
| 49 | 92452 | Air filter outer cover |
| 50 | 92453 | Air filter knob |
| 51 | 79872 | Engine case cover baffle |
| 52 | 79871 | Engine case cover |
| 53 | Standard | M5x16 screw |
| 54 | Standard | Flat washer 5x16x1 |
| 55 | 08070 | Spark plug |
| 56 | 79873 | Fuel tank assy |
| 57 | Standard | M5x25 screw |
| MULTIFUNCTION PLAYCUT 33 cc - 89810 - Powered Shaft Pag.2 | ||
| 1 | 92459 | Aluminum working shaft |
| 2 | 79953 | Clutch Drum Assy |
| 3 | Standard | M5x12 screw |
| 4 | Standard | M6x25 screw |
| 5 | 79947 | Belt connector assy |
| 6 | Standard | M5x20 screw |
| 7 | Standard | M5 nut |
| 8 | 92439 | Hardness axesΦ8x762 |
| 9 | 92443 | Connector joint |
| 10 | Standard | M6x30 screw |
| 11 | 79946 | Throttle trigger assy |
| 12 | Standard | M5x8 screw |
| 13 | 88402 | Loop handle assy |
| 14 | 92438 | Sponge cover A |
| 15 | 92447 | Inner end cap |
| 16 | 92457 | Joint shaft connector |
| MULTIFUNCTION PLAYCUT 33 cc - 89810 - Brushcutter Accessory Pag.3 | ||
| 1 | 92462 | Aluminium working shaft assy φ26x735H |
| 2 | 79952 | Gear case |
| 3 | 79950 | Guard blade holder |
| 4 | 79955 | Protection guard assy |
| 4,2 | Standard | ST4.2x16-H-F |
| 4,3 | 88406 | Protection guard holder |
| 4,5 | Standard | M5x16 screw |
| 4,6 | 79951 | Nylon line cutting blade |
| 4,7 | Standard | ST4.8x20-H-F |
| 5 | 92442 | Drive Shaft φ8x762A |
| 11 | 88609 | Trimmer head DB |
| 12 | 92446 | Outer end cap |
| MULTIFUNCTION PLAYCUT 33 cc - 89810 - Hedgetrimmer Accessory Pag.4 | ||
| 1 | 92464 | Aluminum working shaft assy φ26x735C |
| 2 | 90526 | Hedge trimmer cutter working |
| 2,1 | 92466 | 16" blade cover |
| 5 | 92442 | Drive Shaft Φ8x762A |
| 6 | 92446 | Outer end cap |
| 7 | 92447 | Inner end cap |
| MULTIFUNCTION PLAYCUT 33 cc- 89810 - Pruner Accessory Pag.5 | ||
| 1 | 92463 | Aluminum working shaft assy φ26x760L |
| 2 | 90527 | Fixed saw cutter working head |
| 2,1 | 92468 | Sproket cover |
| 2,2 | Standard | M8 nut |
| 5 | 92442 | Drive Shaft Φ8x782A |
| 6 | 92449 | 10" Guide bar Oregon Double Guard 91 |
| 7 | 61286 | 10" Saw chain |
| 8 | 62125 | Guide bar protection cover 10" |
| 9 | 92446 | Outer end cap |
| MULTIFUNCTION PLAYCUT 33 cc - 89810 - Esctension Accessory Pag.6 | ||
| 1 | 92461 | Aluminum working shaft assy φ26x760H |
| 2 | 92469 | Sponge sheath B |
| 3 | 92458 | Joint shaft connector |
| 5 | Standard | M3x6 screw |
| 6 | 92447 | Inner end cap |
| 7 | 92446 | outer end cap |
| 8 | 92439 | Hardness axes Φ8x762 |
| 9 | 92443 | Connector of hardness axes |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Ama websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Ama brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
