Ama Spare Parts for Chainsaw NBG 38.16

€5.90
Tax included

Ama Spare Parts for Chainsaw NBG 38.16

AMA Garden repair center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Chainsaw NGB 38.16.
ITEM CODE: 10660
Quantity
Usually Ships in: 7/10 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Ama Spare Parts for Chainsaw NBG 38.16

AMA Garden repair center

 and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Chainsaw NGB 38.16.

In the following table, look for the model of the Chainsaw and the respective parts of the code.
Ama NBG 38.16 - 79980

Chainsaw NBG 38.16 Pag.1
# Part Num. Description
1 55066 Cylinder body
6 88147 Silencer cover plate
7 57561 Silencer body
8 57562 Gasket muffler
9 60336 Muffler connecting screw
11 10660 Spark plug
12 57556 Air intake tube sealing gasket
13 57555 Air intake tube
14 57554 Carburetor sealing gasket
15 57557 Cylinder gasket
16 55067 Piston ring
17 55069 Piston pin
18 55071 Piston pin circlip
19 55068 Piston
20 58217 Needle bearing ring
21 58215 Needle bearing 10×14×11
22 88146 Crank shaft components
23 63818 Semicircular key 3×3.5×10
24 88141 Left crank case
25 Bearing 6201 grade D 12×32×10
26 88143 Case body sealing gasket
27 88142 Right crank case
28 Shield ring 32
29 88144 Oil seal 12×32×5.5
31 60331 Double-screw bolt AYM8-M8×26-8.8
32 57565 Tension block
33 57564 Adjust screw M5×48
34 64075 Spiked bumper
36 57566 Chain catcher
37 88139 Chain catcher screw
38 57563 Crankcase-Bar Guard Plate
40 88145 Oil seal 12×22×7
41 57559 Ignition Coil
45 63820 Nut M8×1
46 58205 Flywheel assembly
47 57567 Clutch assembly
51 88148 Clutch adjusting washer
52 57794 Clutch DRUM 3/8
53 57568 Needle bearing 10×13×13
54 55079 Worm Screw
55 88133 Cover plate
56 57570 Oil pump
57 57569 Oil outgoing tube 3×6.5×75
58 88138 Worm washer 10×18×1
59 57569 Oil ingoing tube 3.3×6.5×68
60 88135 Oil tube clip
61 63879 Oil tube tie-in
62 55258 Oil filter screen assy
63 57571 Nozzle
64 57660 Oil filter screen
65 79418 Oil spray nozzle
HANDLEBAR Pag.2
1 88123 Right cover assembly
5 88124 Front damper
6 64030 Heavy brock
7 64031 Heavy brock spring
8 88161 Brake torsion rod spring
11 64029 Spring base
12 64028 Front guard spring
13 64079 Tensioner cover plate
18 64044 Break control rod
19 88152 Brake spring
20 60337 Break strap
22 88151 Break spring cover plate
23 88125 right cover
24 73839 Nut M8
25 88128 Air filter lock nut
26 88155 Lock nut washer 15×26×1
27 88127 Air filter cover
28 57558 Air filter
29 88126 upper cover plate
30 88154 Anti-freeze block
31 88153 Shock block
33 88137 Dust shield
34 88132 Throttle lever retaining bracket
35 58210 Throttle rod
36 88165 Bossing
37 88118 Starter assembly
40 88158 Ratchet wheel
41 88157 Strip spring
42 Start stretching wire3×920
43 88160 Start plate
45 88131 Start coil-spring
46 64061 Start handle
47 88121 Starter cover
49 57552 left dust cover
50 57551 Cushion socket 1
52 57548 Cushion socket 2
53 57550 Right dust cover
54 58206 Front handle spring
55 57547 Front handle
56 88134 Torsion rod spring cover plate
58 63771 Balancer body assembely
59 63885 Balancer root
60 79417 Fuel filter assembly with tube
64 88149 Clump weight
65 88150 Fuel filter assembly
66 88159 Base
67 60333 Base spring
68 88129 Fuel Tank-cap Assy
72 88130 Cap Oil Tank
76 60342 Extinction switch
77A 63833 Primer pump
78A 79415 Primer Pump line
80 57805 Trigger control rack
81 57807 Trigger torsion rod spring
82 57806 Trigger
83 64133 Throttle rod
84 88122 Handle cover
85 79225 Circlip for nozzle
86 88136 Vent tube 3.5×6.5×72
88 79416 Carburetor
89 88140 Carburetor screw
90 64135 Air intake socket
91 88156 Case
93 55087 Chain cover
94 61291 Saw Chain 3/8"LP-0.50" - 1,3mm 57m
94 79535 Saw Chain Oregon
95 55077 Guide Bar 16" AMA Garden
95 84926 Guide Bar 16" Oregon
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Ama websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Ama brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Ama NBG 38.16 - 79980
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 7/10 BUSINESS DAYS APPROX
MORE INFO:
info@bricoutensili.com
New

Download

Diagram Ama NBG 38-16

Diagram Ama NBG 38-16

Download (498.46KB)
