Alpina Spare Parts for Brushcutter BJ 346 (2016) - 280320000
€1.41
Tax included
Alpina Spare Parts for Brushcutter BJ 346 (2016) - 280320000
Alpina-Stiga-Castor-Castelgarden-Mountfield Authorized Technical Assistance and original spare parts Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to solve any maintenance or issues for Brushcutter BJ 346 (2016) - 280320000/ALP.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Alpina Spare Parts for Brushcutter BJ 346 (2016) - 280320000
Alpina-Stiga-Castor-Castelgarden-Mountfield Authorized Technical Assistance and original spare parts Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Brushcutter BJ 346 (2016) - 280320000/ALP
In the following table, look for the model of the Brushcutter and the respective parts of the code.
| ALPINA BJ 346 (2016) - 280320000/ALP pag.1 | ||
| # | Part Num. | Description |
| 1 | 118801251/0 | Screw |
| 2 | 118801250/0 | Hub |
| 4 | 118801249/0 | Starter Pulley |
| 5 | 118801252/0 | Starter rope |
| 6 | 118801253/0 | Spring |
| 9 | 118801263/0 | Starter handle |
| 10 | 118801264/0 | Fermo |
| 11 | 118801262/0 | Black Starter Assembly |
| 12 | 2135030 | Screw |
| 13 | 118801254/0 | Starter Cup Ass'y |
| 17 | 119035159/0 | Seal ring |
| 18 | 118801281/0 | Engine Cover, Starter Side |
| 19 | 123280087/0 | Engine Crankcase Gasket |
| 20 | 119216048/0 | Bearing |
| 21 | 118801278/0 | Crankshaft |
| 22 | 123072002/0 | Flywheel key |
| 24 | 118801280/0 | Engine Cover, Clutch Side |
| 25 | 2135060 | Screw |
| 26 | 118801321/0 | Flywheel |
| 29 | 112154200/0 | Nut |
| 30 | 118801276/0 | Electronic Coil |
| 32 | 2135030 | Screw |
| 35 | 123430583/0 | Clutch arm |
| 37 | 123878058/0 | Screw |
| 53 | 118801284/0 | Ball Bearing |
| 54 | 118801325/0 | Locking Pin |
| 55 | 123760008/0 | Piston pin |
| 56 | 118801279/0 | Piston |
| 57 | 123204017/0 | Piston Ring |
| 58 | 118801282/0 | Cylinder Gasket |
| 59 | 118801270/0 | Cylinder assembly |
| 60 | 2135030 | Screw |
| 61 | 3210024 | Spark Plug |
| 63 | 118801272/0 | Spark Plug Cap |
| 64 | 123275023/0 | Grommet |
| 67 | 118801301/0 | Yellow Cover |
| 68 | 2135030 | Screw |
| 69 | 123280085/0 | Cylinder Intake Manifold Gasket |
| 70 | 118801323/0 | Intake manifold |
| 71 | 112789000/0 | Screw |
| 72 | 123280086/0 | Carburetor Intake Manifold Gasket |
| 73 | 118801268/0 | Carburetor |
| 74 | 118801229/0 | Wing Lever |
| 75 | 118801228/0 | Base + Air Filter Cover |
| 76 | 123190000/0 | Air choke |
| 78 | 2132160 | Screw |
| 79 | 123220011/0 | Air filter |
| 80 | 118801303/0 | Yellow filter cover |
| 81 | 118801277/0 | Muffler gasket |
| 83 | 118801269/0 | Muffler |
| 85 | 118801283/0 | White Cover |
| 86 | 2122210 | Screw |
| 87 | 123280060/0 | seal |
| 88 | 112788910/0 | Screw |
| 89 | 118801274/0 | Fuel tank |
| 90 | 118801417/0 | Lower Protection |
| 91 | 2135030 | Screw |
| 92 | 2135200 | Screw |
| 93 | 118801319/0 | Fuel Tube |
| 94 | 118801318/0 | Rubber grommets |
| 95 | 118801313/0 | Fuel Intake Hose |
| 96 | 183520005/0 | Fuel Filter |
| 97 | 118801243/0 | Tank cap assembly |
| ALPINA BJ 346 (2016) - 280320000/ALP pag.2 | ||
| 1 | 123050012/0 | Clutch drum assembly |
| 2 | 2122080 | Screw |
| 3 | 118801261/0 | Protection |
| 4 | 112610800/0 | Elastic ring |
| 5 | 119216048/0 | Ball Bearing |
| 6 | 112609200/0 | Seeger |
| 7 | 118801259/0 | Clutch Cover |
| 8 | 112760475/0 | Screw |
| 9 | 118801260/0 | Button |
| 10 | 118801316/0 | Reduction |
| 11 | 118801311/0 | Reduction |
| 12 | 118801310/0 | Support |
| 13 | 118801309/0 | Support |
| 14 | 2135020 | Screw |
| 15 | 2135030 | Screw |
| 21 | 183869073/0 | Transmission Tube And Drive Shaft Assembly |
| 22 | 123020038/0 | Drive shaft |
| 31 | 118801337/0 | bracket |
| 32 | 112789000/0 | Screw |
| 33 | 118801335/0 | Safety Lever, Red |
| 34 | 118801336/0 | Throttle Lever, Red |
| 35 | 118801334/0 | Spring |
| 36 | 118801372/0 | Right Handle, Yellow |
| 37 | 112735105/0 | Screw |
| 38 | 118801354/0 | Throttle Cable |
| 40 | 118801333/0 | Spring |
| 41 | 118801329/0 | Red knob |
| 43 | 118801330/0 | Stop Sheet |
| 44 | 118801338/0 | Spring |
| 45 | 118801328/0 | Stop wire |
| 46 | 118801374/0 | Left Handle, Yellow |
| 50 | 118801322/0 | Stop wire Adapter |
| 51 | 183780002/0 | harness support |
| 52 | 123170004/0 | Spacer |
| 55 | 118801381/0 | handle Grip Assembly, Yellow |
| 71 | 118801327/0 | Harness |
| ALPINA BJ 346 (2016) - 280320000/ALP pag.3 | ||
| 1 | 183820507/0 | AssemblitaTestina Gears |
| 6 | 112727801/0 | Screw |
| 7 | 112789000/0 | Screw |
| 8 | 112727794/0 | Screw |
| 10 | 123670002/0 | Protection |
| 15 | 123250002/0 | Upper ring |
| 16 | 123250003/0 | Lower ring |
| 18 | 123120015/0 | Nut |
| 21 | 123784012/0 | Support |
| 22 | 2135050 | Screw |
| 23 | 2135180 | Screw |
| 24 | 118801341/0 | Safety Guard Black |
| 25 | 112735654/0 | Screw |
| 26 | 118801342/0 | Guard, Black |
| 27 | 112728099/1 | Screw |
| 28 | 123311013/0 | Thread cutter sheet |
| 31 | 123155009/0 | 2 Wire Head |
| 32 | 123155010/0 | Disc 3 Tips |
