Alpina Spare Parts for Brushcutter B 28 JD (2015) 280121100/12
€2.19
Tax included
Alpina Spare Parts for Brushcutter B 28 JD (2015) 280121100/12
Alpina original spare parts for the replacement of damaged parts or to repair electrical or mechanical components of the Brushcutter B 28 JD (2015) 280121100/12.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Alpina Spare Parts for Brushcutter B 28 JD (2015) 280121100/12
Alpina original spare parts for the replacement of damaged parts or to repair electrical or mechanical components of the Brushcutter B 28 JD (2015) 280121100/12.
In the following table, look for the model of the Brushcutter and the respective parts of the code.
| ALPINA B 28 JD (2015) 280121100/12 pag.1 | ||
| # | Part Num. | Description |
| 1 | 112789000/0 | Screw |
| 3 | 118801241/0 | Hub |
| 5 | 118801240/0 | Starter Pulley |
| 6 | 118801225/0 | Starter cable |
| 7 | 118801242/0 | Spring |
| 10 | 118801238/0 | Starter handle |
| 11 | 118801239/0 | Locking |
| 12 | 118801237/0 | Black Starter Assy |
| 13 | 2132450 | Screw |
| 14 | 118801226/0 | Starter Cup Assy |
| 18 | 119035159/0 | Seal ring |
| 19 | 123685024/0 | Engine casing, starter side |
| 20 | 123280046/0 | Crankcase Gasket |
| 21 | 114215218/0 | Ball bearing |
| 22 | 123020024/0 | Crankshaft |
| 23 | 123072002/0 | Flywheel Key |
| 25 | 123685025/0 | Crankcase, Clutch Side |
| 26 | 2135060 | Screw |
| 27 | 123880010/0 | Flywheel Assy |
| 30 | 112154200/0 | Nut |
| 31 | 118801231/0 | Electronic Ignition coil |
| 33 | 2135030 | Screw |
| 35 | 123430582/0 | Spring |
| 36 | 123400002/0 | Clutch Unit |
| 38 | 123878057/0 | Screw |
| 51 | 123235006/0 | Needle Bearing |
| 52 | 123202005/0 | Circlip |
| 53 | 123760005/0 | Piston pin |
| 54 | 123590007/0 | Piston |
| 55 | 123204009/0 | Piston Ring |
| 56 | 123280044/0 | Cylinder Base Gasket |
| 57 | 123071013/0 | Cylinder Assy |
| 58 | 112760475/0 | Screw |
| 59 | 3210024 | Spark Plug |
| 61 | 118801232/0 | Spark Plug cap |
| 62 | 123275023/0 | Grommet |
| 63 | 118801233/0 | Cylinder Cover White |
| 64 | 118801245/0 | White cover |
| 65 | 118801255/0 | seal |
| 66 | 112760475/0 | Screw |
| 67 | 123280040/0 | Cylinder Manifold Gasket |
| 68 | 123073508/0 | Intake Manifold |
| 69 | 2135060 | Screw |
| 70 | 118801227/0 | Carburetor-Manifold Gasket |
| 71 | 123054025/0 | Carburetor |
| 72 | 118801229/0 | Shutter Lever |
| 73 | 118801228/0 | Base + Air Filter Cover |
| 74 | 123190000/0 | Air Shutter |
| 76 | 2132160 | Screw |
| 77 | 123220011/0 | Air filter |
| 78 | 118801230/0 | filter cover White |
| 79 | 118801320/0 | seal |
| 80 | 118801247/0 | Muffler gasket |
| 82 | 183740021/0 | Muffler |
| 83 | 118801248/0 | Muffler protection |
| 86 | 6981104 | Outfit, Screws |
| 87 | 123280060/0 | seal |
| 88 | 112788910/0 | Screw |
| 89 | 118801244/0 | Tank |
| 90 | 118801246/0 | Lower Protection |
| 91 | 2135030 | Screw |
| 92 | 2135200 | Screw |
| 93 | 118801319/0 | Fuel Tube |
| 94 | 118801318/0 | Grommet |
| 95 | 118801313/0 | Intake Fuel Tube |
| 96 | 183520005/0 | Fuel Filter |
| 97 | 118801243/0 | Fuel Cap Assy |
| ALPINA B 28 JD (2015) 280121100/12 pag.2 | ||
| 1 | 123050011/0 | Clutch Drum Assy |
| 2 | 112727815/0 | Screw |
| 3 | 118801235/0 | Protection |
| 6 | 112609200/0 | Seeger |
| 7 | 118801234/0 | Clutch Carter White |
| 8 | 2135131 | Screw |
| 9 | 118801236/0 | Button |
| 10 | 118801308/0 | Rubber Sleeve |
| 12 | 118801307/0 | Bottom Clamp |
| 13 | 118801306/0 | Upper Clamp |
| 14 | 112788910/0 | Screw |
| 15 | 2135060 | Screw |
| 21 | 183869072/0 | Transmission Tube Assy |
| 22 | 118801343/0 | Transmission shaft |
| 23 | 118801344/0 | Joint |
| 25 | 183260002/0 | Transmission Shaft Coupling |
| 26 | 123593510/0 | Knob |
| 27 | 183869074/0 | Transmission Tube |
| 28 | 123020035/0 | Transmission shaft |
| 31 | 118801337/0 | bracket |
| 32 | 112789000/0 | Screw |
| 33 | 118801335/0 | Safety Lever, Red |
| 34 | 118801336/0 | Throttle Lever, Red |
| 35 | 118801334/0 | Spring |
| 36 | 118801332/0 | Right Handgrip, White |
| 37 | 112735105/0 | Screw |
| 38 | 118801362/0 | Throttle cable |
| 40 | 118801333/0 | Spring |
| 41 | 118801329/0 | Red Knob |
| 43 | 118801330/0 | Stop Plate |
| 44 | 118801338/0 | Spring |
| 45 | 118801363/0 | Stop Cable |
| 46 | 118801331/0 | Left Handgrip, White |
| 47 | 118801364/0 | Plug |
| 48 | 118801365/0 | grommet |
| 49 | 118801366/0 | grommet |
| 50 | 118801322/0 | Stop Cable Adapter |
| 51 | 118801367/0 | Left grip |
| 52 | 118801368/0 | Handlebar |
| 53 | 112760520/0 | Screw |
| 54 | 2135030 | Screw |
| 55 | 118801355/0 | Upper Handlebar Support |
| 56 | 118801356/0 | Lower Handlebar Support |
| 57 | 118801353/0 | Casing |
| 58 | 118801358/0 | Anti-vibration |
| 59 | 118801359/0 | bracket |
| 60 | 118801360/0 | bracket |
| 61 | 112727796/0 | Screw |
| 62 | 118801357/0 | Casing |
| 63 | 2135030 | Screw |
| 64 | 112728526/0 | Screw |
| 65 | 118801361/0 | Reduction |
| 71 | 118801312/0 | Harness |
| ALPINA B 28 JD (2015) 280121100/12 pag.3 | ||
| 1 | 183820507/0 | Head Gear Ass.y |
| 6 | 112727801/0 | Screw |
| 7 | 112789000/0 | Screw |
| 8 | 112727794/0 | Screw |
| 10 | 123670002/0 | Protection |
| 15 | 123250002/0 | Upper ring |
| 16 | 123250003/0 | Lower Ring |
| 18 | 123120015/0 | Nut |
| 21 | 123784012/0 | Support |
| 22 | 2135050 | Screw |
| 23 | 2135180 | Screw |
| 24 | 118801341/0 | Safety Guard, Black |
| 25 | 112735654/0 | Screw |
| 26 | 118801342/0 | Guard, Black |
| 27 | 112728099/1 | Screw |
| 28 | 123311013/0 | Thread cutter |
| 31 | 123155009/0 | 2-Line head |
| 32 | 123155010/0 | 3-Point Disc |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Alpina websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Alpina brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
