Alpina Spare Parts for Brushcutter B 52 D
€1.53
Tax included
Alpina Spare Parts for Brushcutter B 52 D
STIGA-ALPINA-CASTOR-CASTELGARDEN-Mountfield authorized repair center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Brushcutter ALPINA B 52 D (2018) 287421000/16.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Alpina Spare Parts for Brushcutter B 52 D
STIGA-ALPINA-CASTOR-CASTELGARDEN-Mountfield authorized repair center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Brushcutter ALPINA B 52 D (2018) 287421000/16.
In the following table, look for the model of the Brushcutter and the respective parts of the code.
| ALPINA B 52 D (2018) 287421000/16 - Engine Pag.1 | ||
| # | Part Num. | Description |
| 1 | 118804038/0 | Screw |
| 2 | 118804045/0 | Washer |
| 3 | 118804000/0 | Clutch |
| 4 | 112789008/0 | Screw |
| 5 | 118804033/0 | Flywheel Cover |
| 6 | 118804046/0 | Washer |
| 7 | 112293200/0 | Nut |
| 8 | 112369500/0 | Elastic Washer |
| 9 | 112521350/0 | Washer |
| 10 | 118804013/0 | Flywheel |
| 11 | 2135130 | Screw |
| 12 | 118804025/0 | Crank Case |
| 13 | 118803990/0 | Crankshaft |
| 14 | 118804079/0 | Crankcase Gasket |
| 15 | 118804027/0 | Crank Case |
| 16 | 118804019/0 | Needle Bearing |
| 17 | 118804036/0 | Piston 51.7CC |
| 18 | 118804040/0 | Piston Pin |
| 19 | 118804049/0 | Circlip |
| 20 | 118804023/0 | Piston Ring |
| 21 | 118804080/0 | Cylinder Gasket |
| 22 | 118804035/0 | Cylinder 51.7CC |
| 23 | 118804085/0 | Muffler Gasket |
| 24 | 118803992/0 | Muffler |
| 25 | 118804048/0 | Muffler Guard |
| 26 | 2135180 | Screw |
| 27 | 112521330/0 | Washer |
| 28 | 112582100/0 | Grower |
| 29 | 118801180/0 | Screw |
| 30 | 118804081/0 | Gasket |
| 31 | 118804064/0 | Intake Manifold |
| 32 | 6981102 | Outfit, Screws |
| 33 | 118804083/0 | Carburetor Gasket |
| 34 | 118804009/0 | Carburetor |
| 35 | 118804063/0 | Air Cleaner Base |
| 36 | 112521320/0 | Washer |
| 37 | 112581500/0 | Grower |
| 38 | 2135250 | Screw |
| 39 | 118804074/0 | Air Filter |
| 40 | 118803963/0 | Filter Cover |
| 41 | 118803174/0 | Knob, Grey |
| 42 | 118803996/0 | Starter Cup |
| 43 | 118804051/0 | Gasket |
| 44 | 118803994/0 | Starter Assy |
| 45 | 112727356/0 | Screw |
| 46 | 3210024 | Spark Plug |
| 47 | 322055542/0 | White Cylinder Cover |
| 48 | 112727796/0 | Screw |
| 50 | 118801188/0 | Seal Ring |
| 51 | 3112040 | Ball Bearing |
| 52 | 118804020/0 | Seal Ring |
| 53 | 123072002/0 | Flywheel Key |
| 54 | 118804864/0 | Ignition Assy |
| 56 | 2135110 | Screw |
| 57 | 118804055/0 | Wire Clamp |
| 58 | 112760475/0 | Screw |
| 59 | 118804004/0 | Fuel Tank Assy |
| 60 | 118803962/0 | Support |
| 61 | 118804087/0 | Air Guide |
| 62 | 112727815/0 | Screw |
| 63 | 112727790/0 | Screw |
| 64 | 112523020/0 | Washer |
| 65 | 118803975/0 | Starter Cam |
| 66 | 118804061/0 | Starter Spring |
| 67 | 118803976/0 | Starter Pulley |
| 68 | 118804060/0 | Spring |
| 69 | 118804071/0 | White Starter Plate |
| 70 | 118803984/0 | Starter Handle |
| 71 | 118804068/0 | Rope Guide |
| 72 | 118803163/0 | Spark Plug Cap |
| 73 | 322735152/0 | Oil Cap |
| 74 | 118804005/0 | Fuel Hose |
| 75 | 118803181/0 | Starter Cord |
| ALPINA B 52 D (2018) 287421000/16 - Drive Shaft Pag.2 | ||
| 1 | 118804002/0 | Support Transmission Assy |
| 2 | 118803958/0 | Transmission Pipe |
| 3 | 6981145 | Screw |
| 4 | 112727799/0 | Screw |
| 5 | 112727801/0 | Screw |
| 7 | 112760475/0 | Screw |
| 8 | 112291000/0 | Nut |
| 9 | 118803987/0 | Handle Support |
| 10 | 112727801/0 | Screw |
| 11 | 118803210/0 | Left Handgrip |
| 13 | 123878017/0 | Screw |
| 14 | 112154330/0 | Nut |
| 15 | 118804042/0 | Drive shaft |
| 16 | 118803999/0 | Gear Case Assy |
| 17 | 118804052/0 | plate |
| 18 | 118803954/0 | Safety cover Assy |
| 19 | 2132180 | Screw |
| 20 | 118801125/0 | 3 Teeth Disc |
| 22 | 1911-9227-01 | Line Cutter Head |
| 23 | 118804015/1 | Harness |
| 24 | 118804066/0 | Wire Clamp |
| 25 | 118804037/0 | Clutch Drum |
| 26 | 118804065/0 | Harness Support |
| 27 | 118804062/0 | knob |
| 28 | 118804072/0 | Upper Handgrip Support |
| 29 | 118804075/0 | Lower Handgrip Support |
| 30 | 118803974/0 | White Left Handgrip |
| 31 | 118803964/0 | White Right Handgrip |
| 32 | 118803221/0 | Trigger |
| 33 | 118803219/0 | Safety Lever |
| 34 | 118803213/0 | Switch |
| 35 | 118803220/0 | Spring |
| 36 | 112727810/0 | Screw |
| 37 | 118803986/0 | Throttle cable |
| 38 | 118803217/0 | Stop Wire |
| 39 | 2452090 | Nut |
| 40 | 118804050/0 | Case Dust Cover |
| 41 | 118804043/0 | Upper ring |
| 42 | 118804044/0 | Lower Ring |
| 44 | 118804058/0 | Guard |
| 45 | 112727815/0 | Screw |
| 46 | 118803202/0 | Support |
| 47 | 118804056/0 | Line Cutter Blade |
| 48 | 6981149 | Screw |
| 49 | 112728531/0 | Screw |
| 50 | 118804890/0 | Line Retainer |
| 51 | 118804889/0 | Spring |
| 52 | 118804888/0 | Cover + knob |
| 55 | 118804955/0 | Handle grip ass'y, Yellow |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Alpina websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Alpina brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
