AEG DB1500-2XE Diamond Drill Spare Parts
Fix Your DB1500-2XE Diamond Drill. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.In the following table, look for the model of the Drill Driver and their spare part.
| DB1500-2XE DIAMOND DRILL IN2 Spare Parts 4935412475 - DB1500-2XE - 4000412476 |
||
| # | Part Num. | Description |
| 3 | 4931412481 | RATING PLATE |
| 4 | 4931302112 | CONNECTION CABLE |
| 5 | 4931412483 | NAME PLATE |
| 6 | 4931359575 | CABLE ENTRY SLEEVE |
| 7 | 4931614685 | SCREW D 912 M 4X70 8G |
| 8 | 4931612817 | SCREW |
| 9 | 4931321699 | LABEL |
| 100 | 4931412484 | HOUSING |
| 101 | 4931301483 | RUBBER SLEEVE |
| 102 | 4931412485 | HANDLE |
| 103 | 562578001 | HOLDING-DOWN DEVICE |
| 105 | 4931442730 | ELECTRIC FIELD |
| 106 | 4931426550 | ARMATURE |
| 107 | 4931476088 | FAN |
| 108 | 4931368037 | GROOVED BALL BEAR. |
| 109 | 4931901253 | BALL BEARING |
| 111 | 4931267463 | BEARING COVER |
| 113 | 4931271823 | INSULATING DISC |
| 114 | 4931605127 | RING |
| 116 | 4931337361 | AIR DEFLECTOR RING |
| 117 | 1000000003 | Not available for this version |
| 118 | 4931624538 | SCREW |
| 119 | 4931618253 | SCREW |
| 120 | 4931317546 | BRUSH HOLDER |
| 121 | 4931317544 | BRUSH HOLDER INSUL |
| 125 | 4931256500 | CABLE COLLAR |
| 128 | 4931622342 | CONNECTION CABLE |
| 129 | 4931463248 | PRINTED CIRC. BOARD |
| 130 | 4931300215 | FELT WASHER |
| 131 | 4931392581 | CARBON BRUSH SET |
| 135 | 4931385859 | SWITCH |
| 140 | 4931385864 | CAPACITOR |
| 150 | 4931409768 | HOLDING-DOWN DEVICE |
| 200 | 4931412489 | GEAR BOX |
| 201 | 4931219424 | NEEDLE BEARING |
| 202 | 4931615663 | PIN |
| 203 | 4931307984 | DRILL SPINDLE |
| 204 | 4931621809 | DISC |
| 205 | 4931267406 | PRESSURE SPRING |
| 206 | 4931891058 | BALL BEARING |
| 207 | 4931325240 | PERCUSSION SLEEVE |
| 208 | 4931267522 | SEAL RING |
| 209 | 4931890311 | LOCKING RING |
| 210 | 4931943605 | DISC |
| 211 | 4931368671 | DRILL SPINDLE WHEEL |
| 212 | 4931307130 | SHIFT RING COMPL. |
| 213 | 4931621732 | PIN |
| 214 | 4931369652 | DRILL SPINDLE WHEEL |
| 215 | 4931901226 | DISC N874237 8,1X16X0,5 |
| 217 | 4931307118 | RETAINING SPRING |
| 218 | 4931309010 | SWITCH LEVER |
| 219 | 4931621731 | PIN |
| 221 | 4931621650 | PIN |
| 224 | 4931412490 | BEARING END PLATE |
| 225 | 4931912093 | SLEEVE N874989 HKO 0810 |
| 226 | 4931624661 | BALL BEARING |
| 227 | 4931307995 | GASKET |
| 228 | 4931805437 | BALL |
| 229 | 4931919962 | DISC N874237 8,3X16,5X1 |
| 230 | 4931320109 | SWITCH LEVER |
| 231 | 4931943493 | O-RING N874701 8X1 |
| 235 | 4931310479 | SWITCH LEVER |
| 236 | 4931621782 | O-RING N874701 14X1 |
| 241 | 4931368673 | REDUCTION GEAR |
| 410 | 4931384434 | DEPTH GAUGE |
| 601 | 4931375516 | HANDLE |
| 602 | 4931407017 | CLAMPING RING |
| 608 | 1000000003 | Not available for this version |
| 609 | 1000000003 | Not available for this version |
| 700 | 4931412492 | CARRYING CASE |
| 701 | 4932399174 | FIXTEC ADAPTER FIXTEC M18/16 P1 MET |
| 702 | 4931941117 | O-RING |
| 703 | 4932320014 | Keyed Chuck 3Jaw C 3.0-16 M18x2.5-1pc |
| 711 | 4932352172 | FIXTEC CLR M18X2.5 / 1 1/4 P1M |
| 712 | 1000000003 | Not available for this version |
